Allez Elite Compact
Overview
Technical Specifications
Reviews
Specialized E5 frame with tapered head tube saves weight and improves steering precision.
  • Oversized aluminum handlebar is stiff and light for serious performance
  • Smooth, precise Shimano Tiagra STI shifters offer effortless and reliable performance
  • Race-inspired E5 smooth-welded alloy frame with integrated headset is stiff, light, and fast
  • Adjustable 4-position oversized alloy stem with 31.8mm bar clamp for strength and versatile positioning
  • Ultralight FACT carbon fork and stiff tapered steerer provides precise steering through the tightest turns

Technical Specifications

DRIVETRAIN
CHAIN KMC X9
BOTTOM BRACKET With crankset
CRANKSET Shimano Tiagra
FRONT DERAILLEUR Shimano Tiagra
SHIFT LEVERS Shimano Tiagra STI
CASSETTE Shimano HG-50, 9-speed, 12-25t
CHAINRINGS 50 x 34T
REAR DERAILLEUR Shimano Tiagra
WHEELS
FRONT HUB Forged alloy Hub, sealed bearings, 28 hole, for J bend round spokes
REAR HUB Forged aluminum, 32h, double sealed ball bearings, cassette, QR
INNER TUBES Standard presta valve
SPOKES Stainless 14g
FRONT TIRE Specialized All Condition, 700x23c, aramid bead, 60TPI, w/ Flak Jacket protection
RIMS Mavic CXP22
REAR TIRE Specialized All Condition, 700x23c, aramid bead, 60TPI, w/ Flak Jacket protection
COCKPIT
SADDLE Body Geometry Riva Road, w/ steel rails
TAPE Specialized S-Wrap, w/ gel
SEATPOST Specialized Elite, carbon wrapped alloy, two-bolt clamp, 27.2mm
STEM Specialized Elite-Set, 3D forged alloy, 4-position adjustable, 4-bolt 31.8mm clamp
HANDLEBARS Specialized Elite, 6061 aluminum, 130 drop, 90 reach, 31.8mm
BRAKES
FRONT BRAKE Tektro cold-forged, dual pivot w/ cartridge pads
BRAKE LEVERS Shimano Tiagra STI
REAR BRAKE Tektro cold-forged, dual pivot w/ cartridge pads
ACCESSORIES
PEDALS Black cage, body & toe clips w/ strap
FRAMESET
HEADSET 1-1/8"" upper and 1-1/5"" lower Cr-Mo cartridge bearings integrated w/ headset, 20mm cone spacer with 20mm of spacers
SEAT BINDER Alloy, 31.8mm
FORK Specialized FACT carbon, carbon legs, aluminum crown and steerer, 1.5"" lower bearing
FRAME Specialized E5 aluminum, fully manipulated tubing, smooth weld compact race design, 1.5"" integrated headset
