Riprock 24

2020 Riprock 24

Dirt, street, trails—the Riprock 24 doesn't fit neatly into any one box. It's purpose-built for fun, no matter how your little tike decides to ride it.

With a pair of our ultra-wide, 2.8-inch tires and comfortable, confident geometry, smiles are going to be guaranteed. That's because the big tires and 24-inch wheels provide heaps of traction, control, and confidence over any terrain, while a bump-eating, coil-sprung suspension fork will make quick work of absorbing any rough stuff.

Throw in a set of powerful, low maintenance mechanical disc brakes and a low standover that makes getting the perfect fit a total breeze, and your little munchkin has a bike that's going to make every kid in the neighborhood want to rip and rock around the neighborhood till the sun goes down.

Technical Specifications

ACCESSORIES

Pedals

Nylon platform w/ reflectors

WHEELS

Rims

24", double-wall aluminum

Rear Hub

Alloy, 6-bolt disc, 135mm spacing, 9-speed freehub, loose ball bearings, QR, 32h

Inner Tubes

Schrader valve

Rear Tire

Big Roller, 60 TPI, wire bead, 24x2.8"

Front Hub

Alloy, 6-bolt disc, 110mm spacing, loose ball bearings, QR, 32h

Spokes

Stainless, 14g

Front Tire

Big Roller, 60 TPI, wire bead, 24x2.8"

COCKPIT

Stem

3D-forged alloy, 4-bolt, 6-degree rise, 25.4mm clamp, 60mm

SeatPost

Alloy, single-bolt, 27.2MM

Grips

Specialized, slip-on

Handlebars

Double-butted alloy, 5-degree backsweep, 25.4mm

Saddle

Specialized Kids' Henge

FRAMESET

Frame

Specialized A1 Premium Aluminum, single-butted, ZeroStack head tube, 135mm rear hub spacing, forged dropouts, replaceable derailleur hanger

Fork

SR Suntour XCT, coil spring, preload adjust, 70mm of travel

Seat Binder

Bolt-type, 31.8mm

DRIVETRAIN

Rear Derailleur

Shimano Tourney RD-TX800, 8-speed

Shift Levers

Shimano Tourney, grip shift, 8-speed

Crankset

Forged alloy, 152mm

Chain

KMC Z8, 8-speed w/ reusable Missing Link™

Cassette

SunRace, 8-Speed, 11-34t

Bottom Bracket

BSA, square taper

Chainrings

Steel, 30T

BRAKES

Front Brake

Mechanical disc, organic pads, 6-bolt, tool-less reach adjust, 160mm

Rear Brake

Mechanical disc, organic pads, 6-bolt, tool-less reach adjust, 160mm

* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	11
Crank Length	152mm
Handlebar Width	600mm
Stem Length	60mm
Saddle Width	135mm
Seatpost Length	300mm
Seat Tube Length, Center to Top	567mm
Top Tube Length, Horizontal	510mm
BB Drop	61mm
BB Height	264mm
Chainstay Length	420mm
Seat Tube Angle	73°
Head Tube Angle	69°
Rake	40mm
Wheelbase	989mm
Standover Height	608mm
Head Tube Length	115mm
Reach	336.5mm
