Technical Specifications

FRAMESET

FRAME	Specialized D'Aluisio Smartweld M5 Alloy, XC Geometry, internal cable routing, BSA BB, 12x148mm rear end, triangulated post-mount 160mm brake
SEAT BINDER	Alloy, 30.8mm

WHEELS

FRONT HUB	Specialized disc, 15x110mm spacing, torque caps, 32h
REAR TIRE	Fast Trak, 60 TPI, GRIPTON® compound, 2Bliss Ready, 29x2.1"
RIMS	Stout XC 29, 25mm internal width, disc-specific
REAR HUB	Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
SPOKES	Stainless, 14g
FRONT TIRE	Fast Trak, 60 TPI, GRIPTON® compound, 2Bliss Ready, 29x2.3"
INNER TUBES	Standard, Presta valve

SUSPENSION

FORK	RockShox Reba RL 29, Solo Air, 51mm offset, 15x110mm thru-axle (S: 90mm, M-XL: 100mm of travel)

DRIVETRAIN

CASSETTE	SRAM NX, 11-speed, 11-42t
REAR DERAILLEUR	SRAM GX, long cage, 11-speed
SHIFT LEVERS	SRAM GX, trigger, 11-speed
CHAIN	KMC X11, 11-speed w/ Missing Link™
CRANKSET	Race Face Aeffect
CHAINRINGS	Steel, 30T
BOTTOM BRACKET	Race Face Threaded BSA

COCKPIT

STEM	Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
SADDLE	Body Geometry Phenom Comp, Adaptive Edge design, hollow Cr-Mo rails, 143mm
HANDLEBARS	Specialized Mini-rise, 6000 alloy, 8-degree backsweep, 6-degree upsweep, 10mm rise, 720mm width, 31.8mm clamp
GRIPS	Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
SEATPOST	Specialized, alloy, single-bolt, 27.2mm

BRAKES

REAR BRAKE	SRAM Level TL, hydraulic disc, organic pads, 160
FRONT BRAKE	SRAM Level TL, Hydraulic Disc

ACCESSORIES

PEDALS

Specialized Platform, 9/16" spindle

* Specifications are subject to change without notice

Manual Downloads

2018 Rider/Bike Weight Limits and Terrain Conditions

Specialized Bicycle Owner's Manual (All Languages)

Trainer Usage Addendum to the Bicycle Owner's Manual

Specialized Bicycle Owner's Manual Addendum: Riding With Kids

Specialized Bicycle Owner's Manual (English)

Chisel - Geometry

Geometry

S M L XL

	S	M	L	XL
Crank Length	170mm	175mm	175mm	175mm
Stem Length	70mm	90mm	100mm	110mm
Seatpost Length	350mm	400mm	400mm	400mm
Saddle Width	143mm	143mm	143mm	143mm
Handlebar Width	720mm	720mm	720mm	720mm
Reach	395mm	418mm	441mm	462mm
Top Tube Length, Horizontal	567mm	594mm	622mm	648mm
Stack	595mm	605mm	619mm	633mm
Wheelbase	1073mm	1100mm	1128mm	1154mm
Chainstay Length	430mm	430mm	430mm	430mm
Front Center	650mm	676mm	704mm	730mm
BB Drop	57.5mm	57.5mm	57.5mm	57.5mm
BB Height	312.5mm	312.5mm	312.5mm	312.5mm
Seat Tube Angle	74°	74°	74°	74°
Head Tube Angle	69.8°	69.8°	69.8°	69.8°
Seat Tube Length	400mm	430mm	470mm	520mm
Head Tube Length	95mm	95mm	110mm	125mm
Bike Standover Height	760mm	790mm	814mm	845mm
Fork Rake/Offset	51mm	51mm	51mm	51mm
Fork Length, Full	496mm	506mm	506mm	506mm
Trail	82mm	82mm	82mm	82mm
