Epic Hardtail Expert
SWAT
SWAT EMT Cage-Mount Tool
Frame
Specialized FACT 11m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing
Seat Binder
Specialized Alloy, 34.9mm
Front Tire
Fast Trak, Control Casing, 29x2.3
Inner Tubes
Presta, 60mm valve
Rear Tire
Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3"
Rims
Roval Control Carbon, 25mm internal width, Zero bead hook, Tubeless ready, 28h
Spokes
DT Swiss Competition Race
Front Hub
DT Swiss 350, 15x110mm spacing, Torque caps, 6-bolt, 28h
Rear Hub
DT Swiss 350, Star Ratchet, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Rear Brake
SRAM Level TL, 2-piston caliper, hydraulic disc
Front Brake
SRAM Level TL, 2-piston caliper, hydraulic disc
Fork
RockShox SID SL BRAIN, Bottom-Adjust Brain damper, Debon Air, 15x110mm, 44mm offset, 100mm Travel (XS-80mm Travel)
Tape
Specialized Trail Grips
SeatPost
Specialized Alloy, Single Bolt, 30.9mm
Stem
Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Saddle
Body Geometry Power Sport, steel rails
Handlebars
Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Shift Levers
SRAM X01, trigger, 12-speed
Rear Derailleur
Sram X01 Eagle, 12-speed
Cassette
SRAM XG-1275 Eagle, 12-speed, 10-50t
Bottom Bracket
SRAM DUB, BSA 73mm, threaded
Chain
SRAM GX Eagle, 12-speed
Crankset
SRAM X1 Eagle, DUB, 32T, XS: 165mm, SM: 170mm, M-XL: 175mm
Pedals
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
XS | S | M | L | XL | |
---|---|---|---|---|---|
Crank Length | 165mm | 170mm | 175mm | 175mm | 175mm |
Handlebar Width | 750mm | 750mm | 750mm | 750mm | 750mm |
Stem Length | 60mm | 60mm | 70mm | 70mm | 70mm |
Saddle Width | 155mm | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 350mm | 350mm | 400mm | 400mm | 400mm |
Stack | 594mm | 608mm | 608mm | 622mm | 636mm |
Reach | 385mm | 405mm | 430mm | 455mm | 480mm |
Head Tube Length | 95mm | 95mm | 95mm | 110mm | 125mm |
Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
BB Height | 309mm | 309mm | 309mm | 309mm | 309mm |
BB Drop | 63mm | 63mm | 63mm | 63mm | 63mm |
Trail | 101mm | 101mm | 101mm | 101mm | 101mm |
Fork Length, Full | 486mm | 506mm | 506mm | 506mm | 506mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm | 44mm |
Front Center | 643mm | 670mm | 695mm | 725mm | 755mm |
Chainstay Length | 430mm | 430mm | 430mm | 430mm | 430mm |
Wheelbase | 1064mm | 1092mm | 1117mm | 1148mm | 1178mm |
Top Tube Length, Horizontal | 555mm | 579mm | 604mm | 633mm | 662mm |
Bike Standover Height | 732mm | 762mm | 792mm | 816mm | 847mm |
Seat Tube Length | 367mm | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 74° | 74° | 74° | 74° | 74° |
