2007 S-Works Langster

0 Reviews

Velodrome/Fixed Gear Road As pure a bike as you'll ever find, the Langster likes…

Color:

Black

What's my size?

Imperial

Metric

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Product Details

Velodrome/Fixed Gear Road As pure a bike as you'll ever find, the Langster likes fast friends. Clearly a bike with one gear and no brakes is not for the faint of heart. That's OK, though, because you're not worried about spinning it out down the backside of a small roller or having a little water splash up off the back tire. You're more about the hum a properly tuned fixed-gear bike makes when brought up to speed, the roller-coaster-gone-off-the-tracks feeling of dropping down the banking with a lap to go, or cranking past fellow riders on a shallow climb.

S-Works E5 AEROTEC frame, fully manipulated tubing, compact track racing design, steel dropout protectors
Specialized FACT monocoque carbon fork, full carbon legs, crown and steerer
S-Works FACT carbon stem, 31.8mm handlebar clamp with S-Works Track bar
Shimano Dura-Ace, track crankset
Zipp 404 Track, carbon tubular deep section wheeelset
S-Works Mondo Tubular tires
Body Geometry Toupé Team saddle and S-Works SL, FACT carbon seatpost

Technical Specifications

FRAMESET

FRAME

S-Works E5 AEROTEC, fully manipulated tubing, compact track racing design, steel dropout protectors

FORK

Specialized FACT monocoque carbon fork, full carbon legs, crown and steerer

HEADSET

Specialized Mindset Plus Carbon, 1 1/8"" integrated threadless, cartridge sealed bearings, alloy 20mm cone w/ one 10mm and two 5mm alloy spacers

SEAT BINDER

S-Works, forged/CNC'd, double wedge

WHEELS

FRONT TIRE

S-Works Mondo Tubular, 700x23c

REAR TIRE

S-Works Mondo Tubular, 700x23c

RIMS

Zipp 404 Track, carbon tubular deep section rim

FRONT HUB

Zipp 404 Track, 20 hole, cartridge bearings, carbon dust caps

REAR HUB

Zipp 404 Track, 24 hole, cartridge bearings, carbon dust caps

SPOKES

Stainless 14g aero

DRIVETRAIN

CHAIN

Izumi V, 1/2x1/8"" gold/black

CRANKSET

Shimano Dura-Ace, track

CHAINRINGS

48T

BOTTOM BRACKET

Dura-Ace, track

COCKPIT

STEM

S-Works FACT carbon stem, 31.8mm handlebar clamp

HANDLEBARS

S-Works Track handlebar

SADDLE

Body Geometry Toupé Team, superlight foam, carbon reinforced base, hollow Ti rails, microfiber cover

ACCESSORIES

PEDALS

Composite body test ride pedals

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	49	52	54	56	58	61
Top Tube Length (Horizontal)	510mm	530mm	540mm	555mm	570mm	588mm
Rake	43mm	43mm	43mm	43mm	43mm	43mm
Seat Tube Length, Center to Center	380mm	430mm	450mm	470mm	490mm	520mm
Seat Tube Length, Center to Top	420mm	480mm	500mm	520mm	540mm	570mm
Bottom Bracket Drop	61mm	61mm	59mm	59mm	57mm	57mm
Wheel Base	948mm	960mm	963mm	971mm	979mm	992mm
Standover Height	711mm	739mm	760mm	779mm	800mm	826mm
Head Tube Length	100mm	110mm	130mm	150mm	170mm	195mm
Head Tube Angle	73°	73°	73.5°	74°	74.5°	74.5°
Trail	59mm	59mm	56mm	53mm	50mm	50mm
Front Center	566mm	579mm	580mm	588mm	596mm	608mm
Chainstay Length	390mm	390mm	390mm	390mm	390mm	390mm
Seat Tube Angle	75°	76°	74.5°	74.25°	73.5°	74°
Crank Length	170mm	170mm	170mm	170mm	172.5mm	172.5mm
Handlebar Width	400mm	400mm	400mm	400mm	420mm	420mm
Stem Length	90mm	90mm	100mm	100mm	110mm	120mm
Seatpost Length	300mm	350mm	350mm	350mm	350mm	350mm
