2008 S-Works Carbon HT Disc

0 Reviews

Competitive XC Hardtail DESIGNED TO FLY With a FACT carbon or M5® alloy frame,…

Color:

Gloss Carbon/Black

What's my size?

Imperial

Metric

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Product Details

Competitive XC Hardtail DESIGNED TO FLY With a FACT carbon or M5® alloy frame, the Stumpjumper® is designed to fly with unbeatable efficiency, super low weight and precision handling that'll guide you through even the stickiest of situations. Inside Tech TECH We've been continually refining the Stumpjumper for over two decades, and by now, we've tweaked and tuned the frame materials we use to the point of near perfection (yet, as great as they are, we're always pushing to make them better.) Today's FACT carbon or M5 alloy hardtails both feature completely proprietary frame materials that have been developed by our engineers for unparalleled efficiency, low weight and precision handling. Useful Links FACT Carbon Manuals/Tech Bulletins

S-Works FACT M10 carbon hardtail frame, Az1 constuction, Mono-stay seatstays
Fox F90X, 90mm travel, air spring, inertia valve w/ threshold and rebound adjust, alloy steerer
Shimano New XTR drivetrain and brakes
New Mavic CrossMax SL-R wheelset

Technical Specifications

FRAMESET

FRAME

S-Works FACT 10m carbon hardtail, Az1 constuction, Mono-stay seatstays, forged dropouts w/ disc mount and replaceable derailleur hanger

HEADSET

1 1/8"" threadless, Campy spec integrated sealed cartridge bearing

SEAT BINDER

Alloy single bolt, 36.9mm clamp ID, for carbon frames

SUSPENSION

FORK

Fox F90 RLC, 90mm travel, rebound/compression adjust, lock out w/ threashold adjust, alloy steerer

WHEELS

FRONT TIRE

S-Works Fast Trak LK, 26x2.0"", tubeless ready, aramid bead, dual compound

REAR TIRE

S-Works Fast Trak LK, 26x2.0"", tubeless ready, aramid bead, dual compound

RIMS

Roval Contrôle XC race, disc, 24mm

FRONT HUB

Roval Contrôle XC race, disc, straight pull

REAR HUB

Roval Contrôle XC race, disc, straight pull

SPOKES

Roval Contrôle, straight pull, alloy nipples by DT Swiss

DRIVETRAIN

FRONT DERAILLEUR

Shimano M971 XTR, 34.9 clamp, bottom swing, dual pull

REAR DERAILLEUR

Shimano XTR, Shadow

SHIFT LEVERS

Shimano XTR Rapid Fire trigger

CHAIN

Shimano 7701 XTR

CRANKSET

Shimano M-970 XTR

CHAINRINGS

Shimano XTR 22A/32C/44A

BOTTOM BRACKET

Shimano XTR NEW

COCKPIT

STEM

Thomson CNC alloy, 31.8mm clamp

HANDLEBARS

Specialized XC carbon flat 31.8mm bar, 5 degree backsweep, 580mm wide

SADDLE

Specialized Phenom, Titanium rails

BRAKES

FRONT BRAKE

Magura Marta SL, carbon lever, hydraulic disc, 160mm rotor

REAR BRAKE

Magura Marta SL, carbon lever, hydraulic disc, 160mm rotor

BRAKE LEVERS

Magura Marta SL, carbon lever, hydraulic disc

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	15.5	17	18	19	21
Bottom Bracket Height - Low Setting	301mm	301mm	301mm	301mm	301mm
Top Tube Length (Horizontal)	555mm	585mm	600mm	615mm	640mm
Head Tube Height	125mm	135mm	135mm	145mm	165mm
Head Tube Angle - Low Setting	71°	71°	71°	71°	71°
Seat Tube Angle (Actual) - Low Setting	73°	73°	73°	73°	73°
Top Tube Length (Actual)	531mm	561mm	574mm	590mm	617mm
Seat Tube Length - Center to Top	394mm	432mm	457mm	483mm	533mm
Wheel Base	1028mm	1058mm	1073mm	1089mm	1115mm
Standover Height	761mm	782mm	793mm	810mm	843mm
Chainstay Length	424mm	424mm	424mm	424mm	424mm
Crank Length	170mm	175mm	175mm	175mm	175mm
Handlebar Width	600mm	600mm	600mm	600mm	600mm
Stem Length	70mm	90mm	100mm	110mm	120mm
Seatpost Length	300mm	350mm	350mm	400mm	400mm
