2008 P.Grom

Part No.: 9189-5603

Progressive Hardtail TOP SHELF Top shelf materials, a tried-and-true geometry and testing on every terrain imaginable give the P. Series boundary-busting performance that'll test your courage and help you top the rest. Inside Tech Almost ten years ago, when we first started making the P. Series, it was a little bit of an experiment and we weren't quite sure where it was headed. We just knew we needed a rock-solid rig that could handle everything from dirt jumping to urban assault and freeriding to skate part sessions. As the sport's evolved, so has the P., and today it features one of the most refined and advanced frames--built from either A1™ alloy or 100% Cr-Mo steel--and a parts pick that's tough enough for any terrain.

Color:

Satin Khaki Paisley

Size:

M

Product Details

Technical Specifications

FRAMESET

FRAME

Specialized 100% Cr-Mo, double-butted HT/DT, externally relieved HT, disc mount, 6mm offset horizontal drop out for 24"" wheel w/ replaceable 98954020 alloy hanger, disc only

HEADSET

Tank FX, 1 1/8"" threadless w/ hollow bolt

SEAT BINDER

integrated w/ replaceable single bolt

SUSPENSION

FORK

Marzocchi DJ3, 100mm, 32mm Cr-Mo stanchions and 1 1/8"" Cr-Mo steerer, magnesium lower, fixed rate catridge damping, coil/mcu w/ preload adj., ""stiff"" spring

WHEELS

FRONT TIRE

Specialized Rhythm Sport, 24x2.2"", 30TPI, wire bead w/ flack jacket

REAR TIRE

Specialized Compound Sport, 24x2.1"", 30TPI, wire bead w/ flack jacket

RIMS

Specialized/Alex HRD 24, double wall disc w/ eyelets

FRONT HUB

Specialized P.Disc, CNC high flanges and disc mounts, 36h, nutted 3/8"" axle

REAR HUB

Specialized P.Disc, cassette, CNC high flanges and disc mounts, 36h, nutted 3/8"" axle

SPOKES

2.0mm (14g) stainless

DRIVETRAIN

REAR DERAILLEUR

SRAM X-5, short cage

SHIFT LEVERS

SRAM X-5 trigger

CHAIN

KMC X8, 1/2"" x 3/32"" w/ reusable Missing Link

CRANKSET

Fuse tubular heat treated Cr-Mo 3pc, 165mm

CHAINRINGS

34A w/ poly bash guard and Specialized ISCG chain guide

BOTTOM BRACKET

Fuse Euro, alloy cups, 4x cartridge bearings, 19mm heat treated Cr-Mo 8 spline spindle

COCKPIT

STEM

Truvativ Hussefelt, forged alloy, 31.8mm, 0 degree rise

HANDLEBARS

Specialized butted alloy 31.8mm, 620mm wide, 50mm rise, 8 degree back, 8 degree up sweep

SADDLE

Specialized, 7mm rails, front and rear bumpers

BRAKES

FRONT BRAKE

Avid BB-5, mechanical disc, 6"" G2 Clean Sweep rotor

REAR BRAKE

Avid BB-5, mechanical disc, 6"" G2 Clean Sweep rotor

BRAKE LEVERS

Avid FR-5

ACCESSORIES

PEDALS

Specialized alloy platform, 9/16""

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	L
Bottom Bracket Height - Low Setting	295mm
Top Tube Length (Horizontal)	550mm
Head Tube Height	110mm
Head Tube Angle - Low Setting	69°
Seat Tube Angle (Actual) - Low Setting	71°
Top Tube Length (Actual)	536mm
Seat Tube Length - Center to Top	332mm
Wheel Base	1006mm
Standover Height	684mm
Chainstay Length	390mm
Crank Length	165mm
Handlebar Width	620mm
Stem Length	40mm
Seatpost Length	300mm
