2012 Shiv A1 Frameset
0 Reseñas
The budget-minded Shiv A1 frameset features a lightweight alloy frame with UCI-legal…
Color:
Black/Red
¿Cuál es mi talla?
Seleccione un Tamaño
Detalles del producto
The budget-minded Shiv A1 frameset features a lightweight alloy frame with UCI-legal airfoil tubing and a stiff carbon fork for wind-cheating speed and solid handling. Customize with the spec of your choice.
Shiv Stack and Reach (PDF)
Specialized A1 Premium Aluminum, smooth-weld aero frame is a high-value, high-performance, UCI-legal stealth machine for any race against the clock
Aerodynamic FACT carbon monocoque fork is stiff and stealthy for precision steering and max speed
1-1/8", integrated headset features sealed Cr-Mo bearings for stiffness and durability
FACT carbon 10mm reversible Venge aero seatpost with two setback options for wind-cheating comfort
Especificaciones técnicas
FRAMESET
SEAT BINDER
Venge seat clamp assembly
HEADSET
1-1/8"" sealed Cr-Mo cartridge bearings integrated w/ headset, 20mm alloy cone spacer, w/ 20mm of spacers
FORK
Specialized FACT carbon fork, 1-1/8"", alloy steerer
FRAME
Specialized A1 Premium Aluminum, smooth weld alloy, aero tubing
COCKPIT
SEATPOST
Venge reversible, 10mm offset FACT carbon aero seatpost
* Pesos basados en cuadros pintados de producción como se muestra en la imagen. Los pesos reales variarán en función del color, tamaño del cuadro y variación de componentes. Las especificaciones están sujetas a cambios sin previo aviso.
Geometría
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Ángulo de tubo de asiento | 77° | 77° | 77° | 77° | 77° |
| Largo de tubo de dirección | 98mm | 114mm | 137mm | 161mm | 187mm |
| Seat Tube Length, BB Center to Top | 485mm | 545mm | 570mm | 597mm | 622mm |
| Largo de poste de asiento | 300mm | 300mm | 350mm | 350mm | 350mm |
| Retroceso del tubo de asiento | 0mm | 0mm | 0mm | 0mm | 0mm |
| Ángulo de tubo de dirección | 70.25° | 71.5° | 72° | 72.5° | 72.5° |
| Largo de vaina inferior | 395mm | 395mm | 395mm | 395mm | 395mm |
| Frame Reach | 365mm | 385mm | 405mm | 425mm | 445mm |
| Front-Center | 575mm | 590mm | 609mm | 632mm | 660mm |
| Frame Stack | 495mm | 515mm | 540mm | 565mm | 590mm |
| Top Tube Length | 484mm | 508mm | 533mm | 559mm | 585mm |
| Altura de standover | 725mm | 761mm | 786mm | 812mm | 836mm |
| Rake de horquilla | 50mm | 50mm | 45mm | 45mm | 45mm |
| Caída de caja pedalera | 72mm | 72mm | 72mm | 72mm | 72mm |
| Trail | 68mm | 60mm | 63mm | 59mm | 59mm |
| Distancia entre ejes | 959mm | 974mm | 993mm | 1016mm | 1044mm |
Descargas manuales
Para las advertencias de seguridad, consulte la documentación en la sección Descargas de Manuales de esta página.
