2014 Epic Marathon Carbon 29
$5.199.000
0 Reseñas
With 29-inch wheels, carbon fiber frame, and Brain inertia valve damping technology…
Color:
Gloss Red/Black/White
¿Cuál es mi talla?
Seleccione un Tamaño
Detalles del producto
With 29-inch wheels, carbon fiber frame, and Brain inertia valve damping technology in both the Fox/Specialized shock and custom RockShox SID fork, the Epic FSR Marathon Carbon 29 has the speed to tame any cross-country terrain.
All-new FACT IS 10m carbon frame with M5 seat stays, dedicated 29er geometry and full SWAT technology kit, sealed cartridge bearing pivots on every FSR point, and 142mm dropouts delivers the all-around best performing 100mm-travel Competitive XC bike
FOX/Specialized remote Mini-Brain inertia-valve shock with AUTOSAG and new lighter 2014 tune to seamlessly transition from efficient pedaling on smooth terrain to fully active on rough terrain
Custom RockShox SID 29 fork with Specialized top-mount Brain inertia-valve damping has 100mm of air-sprung travel and 15mm thru-axle to create the most efficient and supple cross-country fork available
Roval Control Carbon 29 142+ hookless carbon wheelset with durable DT Swiss internals, 15mm thru-axle, and stainless DT Swiss spokes brings carbon wheels to a whole new realm of fun
SRAM's X0 trigger shifters matched to a custom SRAM S-2200 carbon double XC crankset with 38/24 gearing is built for strong, yet lightweight performance
Magura MT6 hydraulic disc brakes with a carbon master cylinder and reach adjust provide consistent and reliable stopping power
Especificaciones técnicas
FRAMESET
FRAME
FACT 10m carbon front triangle, SWAT EMT tool cradle, 29"" geometry, FACT IS construction, FACT carbon chainstays, M5 seatstays, tapered headtube, carbon PF30 BB, full internal shift/brake routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 100mm
SWAT
SWAT MTB XC Kit w/ bottle cages, EMT Tool, and Top Cap Chain Tool
HEADSET
1-1/8 and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings
SEAT BINDER
Specialized 7050 hard anodized alloy, single bolt, 31.8mm
SUSPENSION
REAR SHOCK
FOX/Specialized remote Mini-Brain w/ AUTOSAG, inertia valve w/ Aramid hose, Brain Fade adjust, 205x53mm, 100mm travel
FORK
Custom RockShox SID 29 Brain, inertia valve damper, Solo Air spring, tapered alloy steerer, top-mount Brain Fade and rebound adj., 15mm thru-axle, 100mm travel
WHEELS
RIMS
Roval Control Carbon 29, carbon disc, hookless bead, 22mm internal width, 32h
FRONT HUB
Roval Control Carbon 29, 15mm thru-axle, 32h
REAR HUB
Roval Control Carbon 29 142+, DT Swiss Star Ratchet, 12mm thru-axle, 32h
SPOKES
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
FRONT TIRE
S-Works Fast Trak, 2Bliss Ready, 29x2.0"", foldable aramid bead, 120 TPI
REAR TIRE
Specialized Fast Trak Control, 2Bliss Ready, 29x2.0"", foldable aramid bead, 60 TPI
DRIVETRAIN
FRONT DERAILLEUR
Custom SRAM X0, 10-speed, high direct-mount
REAR DERAILLEUR
SRAM X0 Type 2, 10-speed, mid cage
SHIFT LEVERS
SRAM X0, 10-speed, trigger
CASSETTE
SRAM PG-1050, 10-speed, 11-36
CHAIN
SRAM PC 1051, 10-speed, PowerLink
CRANKSET
Custom SRAM carbon S-2200, 10-speed XC double, PF30 spindle, removable spider, S: 170mm, Others: 175mm
CHAINRINGS
38A x 24A, 4-bolt, 104/64mm
BOTTOM BRACKET
SRAM PF30, OS press-in bearings, sealed cartridge
COCKPIT
SADDLE
Body Geometry Phenom Expert, hollow TI rails, 143mm
SEATPOST
Specialized 2014 butted alloy, single bolt setback, 27.2mm, S: 350mm, Others: 400mm
STEM
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
HANDLEBARS
S-Works XC, flat bar, carbon, 700mm wide, 8-degree backsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
BRAKES
FRONT BRAKE
Magura MT6, hydraulic disc, Hi Friction pad, alloy caliper, Storm SL rotor, S/M: 160mm, L/XL: 180mm rotor
REAR BRAKE
Magura MT6, hydraulic disc, Hi Friction pad, alloy caliper, Storm SL rotor, 160mm rotor
BRAKE LEVERS
Magura MT6, carbon master cylinder, alloy lever blade, hollow lever pivot, reach adj.
* Pesos basados en cuadros pintados de producción como se muestra en la imagen. Los pesos reales variarán en función del color, tamaño del cuadro y variación de componentes. Las especificaciones están sujetas a cambios sin previo aviso.
Geometría
| S | M | L | XL | |
|---|---|---|---|---|
| Largo de tubo de asiento, Centro a parte superior | 400mm | 434mm | 470mm | 520mm |
| Largo de tubo superior, Real | 529mm | 557mm | 583mm | 611mm |
| Bottom Bracket Drop | 40mm | 40mm | 40mm | 40mm |
| Altura de caja pedalera | 332mm | 332mm | 332mm | 332mm |
| Ángulo de tubo de asiento, Real | 68.9° | 69.25° | 69.6° | 70° |
| Ángulo de tubo de asiento, Efectivo | 73.75° | 73.75° | 73.75° | 73.75° |
| Distancia entre ejes | 1082mm | 1112mm | 1140mm | 1168mm |
| Altura de standover | 770mm | 774mm | 780mm | 793mm |
| Stack | 587mm | 601mm | 615mm | 634mm |
| Alcance | 393mm | 418mm | 441mm | 462mm |
| Largo de tubo de dirección | 90mm | 105mm | 120mm | 140mm |
| Ángulo de tubo de dirección | 70.5° | 70.5° | 70.5° | 70.5° |
| Largo de vaina inferior | 448mm | 448mm | 448mm | 448mm |
| Largo de tubo superior, Horizontal | 564mm | 593mm | 620mm | 647mm |
| Largo de biela | 170mm | 175mm | 175mm | 175mm |
| Ancho de manubrio | 700mm | 700mm | 700mm | 700mm |
| Largo de avance | 75mm | 90mm | 100mm | 110mm |
| Largo de poste de asiento | 350mm | 400mm | 400mm | 400mm |
Descargas manuales
Para las advertencias de seguridad, consulte la documentación en la sección Descargas de Manuales de esta página.
