S-Works Roubaix Frameset

2006 S-Works Roubaix Frameset

EXPERIENCE: ENDURANCE ROAD Developed and named for a 165-mile suffer-fest run across 500 year-old cobbles, the Roubaix is perfect for anyone who wants to go faster and longer.

Tested and tuned on the toughest roads by members of the Gerolsteiner team and thousands of enthusiasts, the Roubaix--with its dialed geometry, lightweight, high efficiency, supple ride and tuned ergonomics--is regularly first across the line in mountain stages and Saturday morning rides. While most riders won't be seeking UCI points on a Roubaix, everyone will be glad to have a steed that lets them go longer and faster than ever before.

Technische Spezifikationen

FRAMESET

FRAME

S-Works FACT 9r carbon, triple monocoque construction, compact design, Zertz seatstay inserts

FORK

S-Works FACT carbon monocoque construction with Zertz inserts

HEADSET

S-Works Mindset Plus, 1 1/8"" integrated threadless, sealed stainless steel cartridge bearings, carbon 20mm cone with two 5mm alloy spacers

SEAT BINDER

S-Works, CNC alloy

* Gewichte basieren auf der Produktion lackierter Rahmen, wie abgebildet. Tatsächliche Gewichte variieren je nach Farbgebung, Rahmengröße und Komponentenvariation. Spezifikationen können ohne Vorankündigung geändert werden.

Geometrie

	49	52	54	56	58	61
Oberrohrlänge (horizontal)	518mm	537mm	548mm	565mm	582mm	600mm
Versatz	49mm	49mm	49mm	49mm	49mm	49mm
Seat Tube Length, Center to Center	410mm	430mm	450mm	470mm	490mm	520mm
Sitzrohrlänge, Tretlager - Oberkante	450mm	480mm	500mm	520mm	540mm	570mm
Tretlager-Absenkung	73mm	73mm	72mm	72mm	70mm	70mm
Radstand	983mm	989mm	1000mm	1010mm	1029mm	1038mm
Überstandshöhe	724mm	741mm	760mm	780mm	802mm	826mm
Steuerrohrlänge	125mm	145mm	165mm	190mm	215mm	235mm
Steuerrohrwinkel	72°	72°	72°	72.5°	72.5°	73°
Nachlauf	59mm	59mm	59mm	56mm	53mm	56mm
Mitte Tretlager - Mitte V.-Achse	582mm	588mm	595mm	606mm	621mm	628mm
Kettenstreben-Länge	412mm	412mm	415mm	415mm	418mm	420mm
Sitzrohrwinkel	74°	75.5°	73.5°	73.25°	72.5°	73°
Kurbellänge	170mm	170mm	173mm	173mm	175mm	175mm
Lenkerbreite	400mm	420mm	420mm	420mm	440mm	440mm
Vorbaulänge	100mm	90mm	110mm	120mm	120mm	130mm
Länge Sattelstütze	300mm	350mm	350mm	350mm	350mm	350mm
