2008 Stumpjumper Expert Carbon
0 Reviews
Competitive XC Hardtail DESIGNED TO FLY With a FACT carbon or M5® alloy frame,…
Colour:
Gloss Carbon/Silver KL
What's my size?
Select a Size
Product Details
Competitive XC Hardtail DESIGNED TO FLY With a FACT carbon or M5® alloy frame, the Stumpjumper® is designed to fly with unbeatable efficiency, super low weight and precision handling that'll guide you through even the stickiest of situations. Inside Tech TECH We've been continually refining the Stumpjumper for over two decades, and by now, we've tweaked and tuned the frame materials we use to the point of near perfection (yet, as great as they are, we're always pushing to make them better.) Today's FACT carbon or M5 alloy hardtails both feature completely proprietary frame materials that have been developed by our engineers for unparalleled efficiency, low weight and precision handling. Useful Links FACT Carbon Manuals/Tech Bulletins
FACT 9M carbon hardtail frame, Az1 construction with Mono-stay seatstays, forged dropouts and disc mount
Fox F90 RL fork with 90mm travel, rebound/compression adjustment, lock out and alloy steerer
Custom Avid Ultimate 7 hydraulic disc brakes
Shimano M762 XT custom crankset for Specialized
DT Swiss X420 custom rims, 24mm, 28/32hole and DT Swiss Competition spokes
Specialized Hi Lo disc front hub, 28hole with disc mount and sealed cartridge bearings
DT Swiss custom 370 rear hub with DT RWS QR and 32hole
Technical Specifications
FRAMESET
FRAME
FACT 9M carbon hardtail, Az1 constuction w/ Mono-stay seatstays, forged dropouts w/ disc mount and replaceable derailleur hanger
HEADSET
1 1/8"" threadless, alloy cups w/ 10mm insertion, sealed cartridge bearing
SEAT BINDER
Alloy single bolt, 36.9mm clamp ID, for carbon frames
SUSPENSION
FORK
Fox F90 RL, 90mm travel, air spring, rebound/compression adjust w/ lock out, alloy steerer
WHEELS
FRONT TIRE
Specialized Fast Trak Control LK, 26x2.0"", 60TPI, tubeless ready aramid bead, dual compound
REAR TIRE
Specialized Fast Trak Control LK, 26x2.0"", 60TPI, tubeless ready aramid bead, dual compound
RIMS
DT Swiss custom for Specialized X420, 24mm w/ eyelets, 28/32h
FRONT HUB
Specialized Hi Lo disc, 28h CNC flange and disc mount, sealed cartridge bearing, 9mm DT RWS alloy QR
REAR HUB
DT Swiss custom for Specialized 370 with DT RWS QR, 32h
SPOKES
DT Swiss Competition 1.8/1.6mm
DRIVETRAIN
FRONT DERAILLEUR
Shimano M581 LX, 34.9mm clamp, bottom swing, dual pull
REAR DERAILLEUR
SRAM X-0, 9-speed, mid cage
SHIFT LEVERS
SRAM X-9, aluminum 9-speed trigger
CHAIN
SRAM PC-971 w/ Power Link
CRANKSET
Shimano M762 XT custom for Specialized
CHAINRINGS
22S/32A/44A, 4 bolt 104/64mm
BOTTOM BRACKET
Shimano M762 XT custom for Specialized
COCKPIT
STEM
Specialized adjustable rise, 31.8mm clamp, 3D forged w/CNC finish
HANDLEBARS
Specialized XC flat 31.8mm bar, 2014 butted alloy, 6 degree backsweep, 600mm wide
SADDLE
Specialized XC MTB, hollow Cr-Mo rails, SL foam
BRAKES
FRONT BRAKE
Custom Avid Ultimate 7, hydraulic disc, 160mm rotor
REAR BRAKE
Custom Avid Ultimate 7, hydraulic disc, 160mm rotor
BRAKE LEVERS
Custom Avid Ultimate 7, hydraulic disc
ACCESSORIES
PEDALS
Crank Brothers Smarty custom for Specialized
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 15.5 | 17 | 18 | 19 | 21 | |
|---|---|---|---|---|---|
| Bottom Bracket Height - Low Setting | 301mm | 301mm | 301mm | 301mm | 301mm |
| Top Tube Length (Horizontal) | 555mm | 585mm | 600mm | 615mm | 640mm |
| Head Tube Height | 125mm | 135mm | 135mm | 145mm | 165mm |
| Head Tube Angle - Low Setting | 71° | 71° | 71° | 71° | 71° |
| Seat Tube Angle (Actual) - Low Setting | 73° | 73° | 73° | 73° | 73° |
| Top Tube Length (Actual) | 531mm | 561mm | 574mm | 590mm | 617mm |
| Seat Tube Length - Centre to Top | 394mm | 432mm | 457mm | 483mm | 533mm |
| Wheel Base | 1028mm | 1058mm | 1073mm | 1089mm | 1115mm |
| Standover Height | 761mm | 782mm | 793mm | 810mm | 843mm |
| Chainstay Length | 424mm | 424mm | 424mm | 424mm | 424mm |
| Crank Length | 170mm | 175mm | 175mm | 175mm | 175mm |
| Handlebar Width | 600mm | 600mm | 600mm | 600mm | 600mm |
| Stem Length | 70mm | 90mm | 100mm | 110mm | 120mm |
| Seatpost Length | 300mm | 350mm | 350mm | 400mm | 400mm |
Manual Downloads
For safety warning please refer to the documentation in the Manual Downloads section of this page.
