2006 S-Works Epic Carbon Disc
0 Reviews
EXPERIENCE: COMPETITIVE XC Racing is one thing, winning is quite another. The…
Colour:
All Colors 2
What's my size?
Select a Size
Product Details
EXPERIENCE: COMPETITIVE XC Racing is one thing, winning is quite another. The only race bike with a Brain, the 100mm travel Epic knows the fastest way to the finish line. The S-Works Epic has an intelligently engineered front triangle made from our FACT 10m carbon and made using our optimized Az1 (as-one) manufacturing method. We've also done the details right on the Epic, check out the FACT carbon main link, magnesium shock extension, titanium brake bosses and sealed cartridge bearing pivots. The Epic's fully active, fully independent FSR rear suspension is now turbo charged with 100 millimeters of rear travel, sprung by our exclusive Brain shock that automatically adjusts the suspension from firmly efficient in smooth terrain to fully active in the rough stuff. The new Brain Fade feature allows any rider to dial-in a custom balance of efficiency and compliance. Learn about the Brain in our Tech Lab.
All new Az1 FACT carbon front triangle, M5 alloy rear triangle, FACT carbon link, magnesium shock extension, 100mm travel, full cartridge bearing pivots, disc only, replaceable derailleur hanger
Specialized Fox Brain Fade shock, adjustable from hardtail firm to trail tune, air spring, rebound adjust
Fox F100 RLT fork, 100mm travel, air spring, rebound, compression and threshold adjustment with LO
Thomson, CNC 7000 series aluminum stem matched with a Specialized FACT carbon flat bar
Shimano M-965 XTR, hydraulic disc brakes
Full Shimano XTR 27-speed drive train with STI integrated shifter/lever combo
Mavic CrossMax Disc SL, Tubeless compatible with S-Works FasTrak Tubeless, 26x2.00", aramid bead tires
Thomson, 7000 series aluminum seatpost, 2-bolt adjustable
Technical Specifications
FRAMESET
FRAME
All new Az1 FACT carbon front triangle, M5 alloy rear triangle, FACT carbon link, magnesium shock extension, 100mm travel, full cartridge bearing pivots, disc only, replaceable derailleur hanger
HEADSET
1 1/8"" threadless, integrated alloy cups, sealed cartridge bearing
SEAT BINDER
34.9mm clamp, dual bolt for carbon frame/post
SUSPENSION
REAR SHOCK
Specialized Fox Brain Fade shock, adjustable from hardtail firm to trail tune, air spring, rebound adjust, 11.7"" X 1.875""
FORK
Fox F100 RLT, 100mm travel, air spring, rebound, compression and threshold adjustment with LO
WHEELS
FRONT TIRE
Specialized S-Works FasTrak Tubeless, 26x2.00"", aramid bead
REAR TIRE
Specialized S-Works FasTrak Tubeless, 26x2.00"", aramid bead
RIMS
Mavic CrossMax Disc SL, Tubeless compatible
FRONT HUB
Mavic CrossMax Disc SL with Mavic QR
REAR HUB
Mavic CrossMax Disc SL with Mavic QR
SPOKES
Mavic CrossMax Disc SL, forged aluminum
DRIVETRAIN
FRONT DERAILLEUR
Shimano M-960 XTR, 34.9mm clamp, bottom swing, dual pull
REAR DERAILLEUR
Shimano M-952 XTR, SGS cage, standard spring
SHIFT LEVERS
Shimano M-965 XTR, STI integrated shifter/lever combo
CASSETTE
Shimano M-960 XTR, 9-speed, 11-34t Ti
CHAIN
Shimano CN-7701 XTR
CRANKSET
Shimano M-960 XTR, Hollowtech II arms
CHAINRINGS
22A/32/44 7075 aluminum
BOTTOM BRACKET
Shimano M-960 XTR
COCKPIT
STEM
Thomson, 31.8mm clamp, 4-bolt face plate, CNC 7000 series aluminum, 0 degree rise
HANDLEBARS
Specialized FACT carbon flat bar, 580mm width, 31.8mm
GRIPS
Specialized MTB grip, black/charcoal
SADDLE
Specialized Body Geometry Rival, titanium rails
BRAKES
FRONT BRAKE
Shimano M-965 XTR, hydraulic disc, 6"" XT rotor, metallic pads
REAR BRAKE
Shimano M-965 XTR, hydraulic disc, 6"" XT rotor, metallic pads
BRAKE LEVERS
Shimano M-965 XTR, STI integrated shifter/lever combo
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| S | M | L | XL | |
|---|---|---|---|---|
| Bottom Bracket Height Low/Mid | 331mm | 331mm | 331mm | 331mm |
| Head Tube Angle Low/Mid | 70.5° | 70.5° | 70.5° | 70.5° |
| Seat Tube Angle Low/Mid | 74° | 74° | 74° | 74° |
| Top Tube Length (Horizontal) | 554mm | 589mm | 615mm | 641mm |
| Top Tube Length (Actual) | 538mm | 572mm | 597mm | 624mm |
| Seat Tube Length, Centre to Top | 394mm | 444mm | 483mm | 533mm |
| Wheel Base | 1058mm | 1094mm | 1120mm | 1149mm |
| Standover Height | 762mm | 769mm | 788mm | 791mm |
| Head Tube Length | 124mm | 136mm | 146mm | 176mm |
| Chainstay Length | 427mm | 427mm | 427mm | 427mm |
| Crank Length | 170mm | 175mm | 175mm | 175mm |
| Handlebar Width | 580mm | 580mm | 580mm | 580mm |
| Stem Length | 75mm | 90mm | 105mm | 120mm |
| Seatpost Length | 350mm | 350mm | 400mm | 400mm |
