The Roll 1 is simplicity at its finest. The classic steel frame absorbs the shocks,…

Colour:

Black_Black

What's my size?

Imperial

Metric

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Choose the colour and size you're looking for to search nearby store inventory.

Unavailable

This item is not available for Find Nearby

Product Details

The Roll 1 is simplicity at its finest. The classic steel frame absorbs the shocks, lasts a lifetime, and jumps when you say go. Set it up fixed or free as you prefer and keep your head up in traffic with a flat handlebar.

Narrow alloy riser bars with15-degree back sweep allows riders to squeeze through tiny gaps with ease
Well-built, classic Cr-Mo singlespeed frame with horizontal dropouts is simple, smooth, and durable
Well-built, classic Cr-Mo singlespeed frame with horizontal dropouts is simple, smooth, and durable
Strong, eye-catching deep V 700c rims and bolt-on, high-flange front and rear hubs complement the Roll's durable urban design
Well-built, classic Cr-Mo singlespeed frame with horizontal dropouts is simple, smooth, and durable
Well-built, classic Cr-Mo singlespeed frame with horizontal dropouts is simple, smooth, and durable

Technical Specifications

FRAMESET

FRAME

Cr-Mo frame TT/ST/DT, track dropouts, brake drilling, fender braze-ons

SUSPENSION

FORK

Globe uni-crown Cr-Mo fork, w/ integrated cast drop outs, hidden Globe Accessory mounting eyelets

COCKPIT

HANDLEBARS

Globe Roll, custom alloy riser bar, 50mm rise, 4-degree upsweep, 15-degree backsweep

STEM

Globe Roll 1" forged quill-stem

HEADSET

1" threaded, sealed loose ball bearings

TAPE

Globe Roll w/ custom alloy end plug

SADDLE

Padded Roll saddle

SEATPOST

Alloy, 2-bolt forged head, 27.2mm, 12.5mm offset

SEAT BINDER

Globe forged-alloy extra slim clamp, 28.6mm

WHEELS

RIMS

700c deep V, 32mm rim depth, machine sidewall, 32h

FRONT HUB

Globe Roll, loose ball, high flange with custom CNC detail, bolt-on, 32h

REAR HUB

Globe Roll, loose ball, high flange flip-flop, bolt-on, 32h

SPOKES

Stainless, 14g

FRONT TYRE

Specialized Espoir Sport, double BlackBelt, 60TPI, wire bead, 700x23c

REAR TYRE

INNER TUBES

Presta valve

DRIVETRAIN

CASSETTE

Freewheel, 17T

CRANKSET

Forged alloy-arm, singlespeed, alloy ring

CHAINRINGS

42T Forged alloy track

BOTTOM BRACKET

Cartridge bearing, square spindle, w/ crank stop right side, capless bolts

CHAIN

KMC Z-510HX singlespeed

BRAKES

FRONT BRAKE

Melt-forged alloy caliper, cartridge pads

REAR BRAKE

Melt-forged alloy caliper, cartridge pads

BRAKE LEVERS

Forged alloy

ACCESSORIES

PEDALS

Alloy cage and body, steel toe clips

* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	SM	MD	LG	XL
Seat-Tube Angle	76.5°	74°	73.25°	72.5°
Head-Tube Length	82.5mm	92.5mm	142.5mm	192.5mm
Seat-Post Length	300mm	300mm	350mm	350mm
Head-Tube Angle	71°	72.5°	73°	73.5°
Chain-Stay Length	392mm	392mm	395mm	395mm
Top-Tube Length, Horizontal	520mm	550mm	580mm	610mm
Front-Centre	610mm	596mm	614mm	630mm
Handle-Bar Width	470mm	470mm	470mm	470mm
Stand-Over Height	737mm	768mm	814mm	862mm
Seat-Tube Length, B-B Centre to Top	480mm	530mm	580mm	630mm
Fork Rake	45mm	45mm	45mm	45mm
B-B Drop	60mm	60mm	60mm	60mm
Trail	69mm	60mm	57mm	52mm
Wheelbase	985mm	980mm	1002mm	1018mm
Crank Length	165mm	165mm	165mm	170mm
Stem Length	80mm	80mm	100mm	100mm
