2015 Epic Elite Carbon World Cup

0 Reviews

With 29-inch Roval Control wheels, FACT 9m carbon frame with World Cup Geometry,…

Colour:

Gloss Rocket Red/Black

What's my size?

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Product Details

Add Icon

With 29-inch Roval Control wheels, FACT 9m carbon frame with World Cup Geometry, and Brain inertia valve damping technology in both the FOX/Specialized shock and custom 95mm-travel RockShox SID fork, the Epic Elite Carbon World Cup has the speed to tame any cross-country terrain.

  • FACT 9m carbon, 95mm-travel, FSR frame w/ World Cup Geometry for premium XC performance

  • FACT 9m carbon, 95mm-travel, FSR frame w/ World Cup Geometry for premium XC performance

  • New Roval Control 29 142+ alloy wheelset w/ 142+ spacing for greater control

  • SRAM X1 11-speed rear derailleur for premium shifting performance

  • FACT 9m carbon, 95mm-travel, FSR frame w/ World Cup Geometry for premium XC performance

  • FACT 9m carbon, 95mm-travel, FSR frame w/ World Cup Geometry for premium XC performance

  • Lightweight and compliant Specialized alloy seatpost

  • FACT 9m carbon, 95mm-travel, FSR frame w/ World Cup Geometry for premium XC performance

Technical Specifications

Add Icon

FRAMESET

FRAME

FACT 9m carbon, 29"" World Cup Geometry, FACT IS construction, FACT carbon front triangle, M5 alloy rear triangle, tapered headtube, carbon PF30 BB, full internal cable routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, SWAT EMT tool cradle, 95mm travel

SWAT

SWAT MTB XC Kit w/ bottle cages, EMT Tool, and Top Cap Chain Tool Compatible (EMT tool included)

HEADSET

1-1/8"" and 1-1/2"" threadless, Campy style upper with 1-1/2"" lower, cartridge bearings

SEAT BINDER

Alloy, 31.8mm

SUSPENSION

REAR SHOCK

FOX/Specialized remote Mini-Brain w/ AUTOSAG, inertia valve, BrainFade adjust, 200x48mm, 95mm travel

FORK

RockShox SID 29 Brain, Solo Air spring, tapered alloy steerer, bottom-mount BrainFade, rebound adjust, 15mm thru-axle, 95mm travel

WHEELS

RIMS

Roval Control 29, alloy, 21mm inner width, 32h

FRONT HUB

Roval Control 29, 15mm thru-axle, 32h

REAR HUB

Roval Control 29 142+, XX1 driver body, 12mm thru-axle, 32h

SPOKES

DT Swiss Revolution

FRONT TIRE

S-Works Fast Trak Control, 120TPI, 2Bliss Ready, folding bead, 29x2.0""

REAR TIRE

Specialized Fast Trak Control, 60TPI, 2Bliss Ready, folding bead, 29x2.0""

DRIVETRAIN

REAR DERAILLEUR

SRAM X1, 11-speed, alloy cage

SHIFT LEVERS

SRAM X1, 11-speed, trigger

CASSETTE

SRAM XG 1180, 11-speed, 10-42

CRANKSET

SRAM X1 1000, 11-speed, PF30, Clean Spider, 32T, 94mm BCD spider

BOTTOM BRACKET

SRAM PF30, OS press-in bearings

COCKPIT

SADDLE

Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm

SEATPOST

Specialized alloy, single bolt, 27.2mm

STEM

Specialized, 3D-forged alloy, 4-bolt, 6-degree rise

HANDLEBARS

Specialized flat, 8-degree backsweep, 31.8mm

GRIPS

Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness

BRAKES

FRONT BRAKE

Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, Storm SL rotor, S/M: 160mm rotor, Others: 180mm

REAR BRAKE

Magura MTS, hydraulic disc, Hi Friction pad, alloy master cylinder, alloy caliper, 160mm Storm SL rotor

BRAKE LEVERS

Magura MTS, alloy lever

ACCESSORIES

PEDALS

Resin Test Ride Pedals with toe clips, CEN std.

* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

Add Icon
SMLXL
Seat Tube Length, Centre to Top400mm434mm470mm520mm
Top Tube Length, Actual529mm557mm583mm611mm
Bottom Bracket Drop40mm40mm40mm40mm
Bottom Bracket Height332mm332mm332mm332mm
Seat Tube Angle, Actual69.4°69.75°70.1°70.5°
Seat Tube Angle, Effective74.25°74.25°74.25°74.25°
Wheel Base1073mm1103mm1131mm1157mm
Standover Height770mm774mm780mm793mm
Stack583mm597mm611mm630mm
Reach398mm423mm446mm465mm
Head Tube Length90mm105mm120mm140mm
Head Tube Angle71°71°71°71°
Chainstay Length439mm439mm439mm439mm
Top Tube Length, Horizontal562mm592mm618mm643mm
Crank Length170mm175mm175mm175mm
Handlebar Width700mm700mm700mm700mm
Stem Length75mm90mm100mm110mm
Seatpost Length350mm400mm400mm400mm
Geometry
