2017 Epic FSR Comp Carbon

0 Reviews

Cross country racing has its own list of demands, and speed is at the top of the…

Color:

GLOSS CARBON/NEON BLUE

What's my size?

Imperial

Metric

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Product Details

Cross country racing has its own list of demands, and speed is at the top of the list. Our Epic FSR Comp Carbon answers the call with an aggressive XC 29 geometry, along with short, nimble chainstays and an exquisite construction. As for the build, you truly start to see the theme of uncompromising speed at work, as we've hung some of Shimano's most reliable parts on this bike. And to make sure that you'll be utilizing every watt of power out of them, we included our Mini Brain rear shock that differentiates rider input from trail bumps to ensure that the bike stays stiff when you need it to. With all of this going on, it's easy to see why the Epic has long been the dominant force on the cross country scene.

By pairing a FACT 9m carbon fiber frame w/ an M5 alloy rear end with our XC 29 Geometry, this Epic places a focus on tight tube angles and light overall weight for explosive speed and nimble handling on the race circuit.
A RockShox Reba RL 29 fork offers up 100mm of smooth travel, while an easily accessible compression and rebound adjusts permit you to customize the feel according to the terrain at hand.
Shimano Deore XT 11-speed rear derailleur is tough, reliable, and incredibly precise.

Technical Specifications

FRAMESET

FRAME

FACT 9m , carbon front triangle, M5 alloy rear end, XC Geometry, PF30 BB, carbon headset cups, 12x142mm rear spacing, internal cable routing, 100mm of travel, SWAT™ tool cradle

SEAT BINDER

Specialized, alloy, 31.8mm

WHEELS

RIMS

Roval Control, hookless alloy, 21mm inner width, 32h, tubeless ready

FRONT HUB

Specialized disc, alloy, sealed cartridge bearings,15x100mm thru-axle, 32h

REAR HUB

Specialized disc, alloy, sealed cartridge bearings,12x142mm thru-axle, 32h

SPOKES

DT Swiss Industry, stainless, 3x, 2.0""

FRONT TIRE

Fast Trak, Control casing, 29x2.2"", 60TPI, Aramid folding bead, 2Bliss Ready

REAR TIRE

Fast Trak, Control casing, 29x2.2"", 60TPI, Aramid folding bead, 2Bliss Ready

SUSPENSION

FORK

Custom RockShox Reba RL, rebound adjust, Solo Air spring, tapered alloy crown/steerer, 15x100mm Maxle Stealth thru-axle, 100mm of travel, 51mm offset

DRIVETRAIN

FRONT DERAILLEUR

Shimano SLX 7025, direct-mount, down-swing

REAR DERAILLEUR

Shimano Deore XT M8000, Shadow Plus, SGS cage, 11-speed

SHIFT LEVERS

Shimano SLX M7000, 11-speed

CASSETTE

Shimano SLX M7000, 11-speed, 11-42t

CHAIN

KMC X11EL, 11-speed w/reusable MissingLink

BOTTOM BRACKET

PF30

CRANKSET

RaceFace Aeffect, 6000-series alloy, 24mm spindle, 49mm chainline, 34/24T

COCKPIT

STEM

Specialized, 3D-forged alloy, 4-bolt, 6-degree rise

HANDLEBARS

Specialized Mini-rise, 6000 alloy, 8-backsweep, 6-upsweep, 10mm rise, 720mm width, 31.8mm clamp

GRIPS

Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness

SADDLE

Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm

SEATPOST

Specialized, Alloy, 27.2mm

BRAKES

REAR BRAKE

Shimano M506, hydraulic disc, resin pad, 160mm rotor

FRONT BRAKE

Shimano M506, hydraulic disc, resin pad, 180/160mm rotor

* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	S	M	L	XL
Crank Length	170mm	175mm	175mm	175mm
Handlebar Width	720mm	720mm	720mm	720mm
Stem Length	70mm	90mm	100mm	110mm
Saddle Width	143mm	143mm	143mm	143mm
Seatpost Length	350mm	400mm	400mm	400mm
Seat-Tube Angle	74°	74°	74°	74°
Head-Tube Length	90mm	105mm	120mm	140mm
Head-Tube Angle	70.5°	70.5°	70.5°	70.5°
Chain-Stay Length	448mm	448mm	448mm	448mm
Front-Center	634mm	664mm	692mm	720mm
B-B Drop	40mm	40mm	40mm	40mm
B-B Height	332mm	332mm	332mm	332mm
Bike Stand-Over Height	770mm	774mm	780mm	793mm
Fork Length (full)	506mm	506mm	506mm	506mm
Top-Tube Length (horizontal)	564mm	593mm	620mm	647mm
Seat-Tube Length	400mm	434mm	470mm	520mm
Stack	587mm	601mm	615mm	634mm
Reach	393mm	418mm	441mm	462mm
Trail	84mm	84mm	84mm	84mm
Fork Rake/Offset	46mm	46mm	46mm	46mm
Wheelbase	1082mm	1112mm	1140mm	1168mm
