Allez DSW SL Sprint Comp
R26,400.00
Part No.:

Allez DSW SL Sprint Comp

R26,400.00
Part No.:  118194
load-spinner
Allez DSW SL Sprint Comp
Overview
Technical Specifications
Geometry
Climbs, corners, flat-out sprints—the Allez DSW SL Sprint Comp does it all. Even better, it performs all of the above at a price that's affordable for any racer's budget. At the heart of it is our DSW Sprint Technology, which strategically places more welding material where it's needed, resulting in an aluminium bike that's more compliant and considerably stiffer. How stiff, exactly? It's the stiffest alloy bike we've ever tested. Drawing inspiration from the Rider-First Engineered Tarmac, this frame has a unique down tube, bottom bracket shell, and head tube, plus fork sizes that correspond to frame size. This ensures uniform performance across the entyre size run. Making sure every single watt you produce gets transferred to the road, it has short chainstays that create an extremely stiff and rigid rear triangle. But it goes beyond just pure rigidity, as the hydroformed tube shapes have also been aerodynamically optimized to slice through the wind. For the build, we spec'd it with Shimano Ultegra shifting, Axis Elite alloy wheels, and a stiff Praxis Alba 2D crankset.
  • E5 Premium aluminium frame with Allez D'Aluisio Smartweld Technology refocuses weld locations, allowing for more material to be placed where it's needed for increased stiffness and compliance where you really need it.
  • Our top-tier S-Works FACT carbon fibre fork provides incredible stiffness and front end steering response, while also efficiently absorbing road chatter.
  • The Praxis Alba 2D crankset is an incredibly stiff crankset with supreme ramping for precise shifts between the rings.

Technical Specifications

FRAMESET
SEAT BINDER Allez Sprint Aero
FORK S-Works FACT full carbon, size-specific taper
FRAME Specialized E5 Premium Aluminum w/D'Aluisio Smartweld Sprint Technology, hydroformed aluminum tubing, tapered head tube, OSBB
DRIVETRAIN
BOTTOM BRACKET Praxis
CHAIN KMC X11, 11-speed w/reusable MissingLink
CRANKSET Praxis Alba 2D
FRONT DERAILLEUR Shimano 105, braze-on
CASSETTE Shimano 105, 11-speed, 11-28t
SHIFT LEVERS Shimano 105 STI, 11-speed
CHAINRINGS 52/36T
REAR DERAILLEUR Shimano 105, 11-speed
COCKPIT
SADDLE Body Geometry Toupé Sport, steel rails, 143mm
TAPE Specialized S-Wrap
SEATPOST Specialized Venge, FACT carbon
HANDLEBARS Specialized Shallow Drop, alloy, 125mm drop, 70mm short-reach
STEM Specialized, 3D forged alloy, 4-bolt, 7-degree rise
BRAKES
FRONT BRAKE AXIS 2.0
REAR BRAKE AXIS 2.0
WHEELS
REAR WHEEL Axis Elite, QR
INNER TUBES 700x20/28mm, 40mm Presta valve
FRONT TYRE Turbo Pro, 700x24mm, 60TPI, folding bead, BlackBelt protection
REAR TYRE Turbo Pro, 700x24mm, 60TPI, folding bead, BlackBelt protection
FRONT WHEEL Axis Elite, QR

Geometry

Geometry Chart

Allez - Geometry

  49 52 54 56 58 61
Crank Length 170mm 170mm 172.5mm 172.5mm 175mm 175mm
Stem Length 80mm 90mm 100mm 100mm 110mm 110mm
Saddle Width 143mm 143mm 143mm 143mm 143mm 143mm
Handlebar Width 400mm 420mm 420mm 420mm 440mm 440mm
Seat Post Length 330mm 330mm 330mm 330mm 330mm 330mm
Reach 375mm 380mm 385mm 395mm 400mm 405mm
Stack 502mm 514mm 533mm 554mm 583mm 604mm
Wheelbase 959mm 961mm 972mm 984mm 997mm 1005mm
Bike Stand-Over Height 732.3mm 745.8mm 765.5mm 784.3mm 808.3mm 833.8mm
Head-Tube Length 100mm 110mm 130mm 150mm 180mm 200mm
Front-Center 564mm 566mm 577mm 589mm 602mm 608mm
Fork Rake/Offset 44mm 44mm 44mm 44mm 44mm 44mm
Head-Tube Angle 72.25° 73° 73° 73.5° 73.5° 74°
Trail 63mm 58mm 58mm 55mm 55mm 52mm
B-B Height 272.5mm 272.5mm 272.5mm 272.5mm 272.5mm 272.5mm
Chain-Stay Length 405mm 405mm 405mm 405mm 405mm 407mm
Fork Length (full) 368mm 368mm 368mm 368mm 368mm 368mm
Seat-Tube Angle 74° 74° 74° 74° 74° 74°
B-B Drop 69mm 69mm 69mm 69mm 69mm 69mm
Seat-Tube Length 460mm 480mm 500mm 520mm 540mm 570mm
Top-Tube Length (horizontal) 519mm 527mm 538mm 554mm 567mm 578mm
