It's what's inside that counts, and the same rings true with the Turbo Vado 5.0.…
Color:
Cast Battleship/Black/Chrome
It's what's inside that counts, and the same rings true with the Turbo Vado 5.0. Each component, from the motor to the battery, works in perfect harmony to provide you with a fully integrated, pedal-assist-system that's the perfect accomplice to your hectic schedule. And with its modern aesthetic and feel, this Vado has truly raised the bar for e-bike design. It's you, only faster.
Beginning with the integrated Specialized 1.3 motor, the Vado proves itself as the ultimate city bike. It features a silently operating design with our Custom Rx Street tune that takes the output and makes it the most usable for the urban environment. Think of it this way: The more power you put out, the more power the motor puts out, and this makes accelerations from a standstill both quick and efficient. The belt driven motor is also smooth, silent, and free of annoying vibrations. Perfect.
For the Vado 5.0, we developed a custom 604 Wh battery that seamlessly integrates into the frame, is lockable, and easily removable for simplified charging. In other words, there's plenty of juice to take you to and from work, a trip to the grocery store, or even to that new café on the other side of the city. If you wish to see exactly how far you can go on a charge, have a look at our Turbo Range Calculator for more exact estimates.
We also developed a custom 2.2-inch smart computer that lets you view your battery level and toggle various ride metrics such as speed, distance, and time. You can also peruse these screens via the custom handlebar remote without ever removing your hands from the bars.
To top off all of these innovative features, we chose a high-end spec, so you'll find Shimano XT/SLX 11-speed components, Shimano XT hydraulic disc brakes, racks, and fenders. It's ready to take your riding to the next level.
The Vado features a lightweight alloy frame that’s been designed with our Fitness/Transportation Geometry.
The Vado’s Specialized 1.3 motor with Rx Street Tune is fully integrated with the frame, and it's also been custom-tuned for city riding. It intuitively reacts to the force of your pedaling, so the harder you pedal, the more power it delivers. And with an internal belt drive design, it does this without added vibration for the smoothest and most silent ride possible.
We made the custom 604 Wh battery to be fully integrated with the frame, removable for easy charging, and lockable for added security. It communicates with the display and has multiple modes to maximize the overall efficiency and range.
FRAME
Turbo Aluminum, bottom bracket motor mount, Fitness/Transportation Geometry, fully integrated & lockable down tube battery, internal cable routing, fender/rack mounts, Smooth Welds
FORK
SR Suntour NCX E25, alloy steerer, 15mm thru-axle, 44mm offset, 50mm of travel
SEAT BINDER
Alloy, 34.9mm
STEM
Specialized Flowset, alloy, 20-degree w/ display/light mount, 31.8mm
HANDLEBARS
Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
GRIPS
Body Geometry XC Contour
SADDLE
Specialized Canopy Comp, hollow Cr-Mo rails, 155mm
SEATPOST
Specialized, alloy, single-bolt, 21mm offset, 30.9mm
REAR BRAKE
Shimano Deore XT T8000, hydraulic disc, 160mm
FRONT BRAKE
Shimano Deore XT T8000, hydraulic disc, 180mm
REAR DERAILLEUR
Shimano XT, Shadow Plus, GS cage, 11-speed
SHIFT LEVERS
Shimano SLX, 11-speed
CASSETTE
Shimano SLX, 11-speed, 11-42t
CHAIN
Shimano Ultegra
CRANKSET
Custom alloy-forged crankarms
CHAINRINGS
40T, 104 BCD w/ chainguard
RIMS
700C disc, double-wall alloy, sleeved
FRONT HUB
Specialized front hub disc, sealed bearings, 15mm thru-axle, 32h
REAR HUB
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES
DT Swiss Industry
FRONT TIRE
Trigger Sport Reflect, 700x47mm
REAR TIRE
Trigger Sport Reflect, 700x47mm
INNER TUBES
Presta, 40mm valve
MOTOR
Specialized 1.3, custom Rx Street-tuned motor, 250W nominal
UI/REMOTE
Custom 2.2" LCD display, USB plug, stem mount w/ custom handlebar remote
BATTERY
Specialized U1-600, On/Off button, state of charge display, 600Wh
CHARGER
Custom charger, 42V4A w/ Rosenberger plug
WIRING HARNESS
Custom Specialized wiring harness
PEDALS
Specialized Commuter w/ grip tape & reflectors
HEADLIGHT
Supernova V521s, 205lm w/ Up-Side-Down Mount to the stem
TAILLIGHT
Supernova E3, alloy housing, 3-LED, 250-degree visibility, fender mount
KICKSTAND
Specialized kickstand, 40mm mount
RACK
Turbo Rack, Closed Platform, direct fender mount, Racktime-compatible
FENDERS
Specialized DRYTECH fenders, 52mm width, stainless steel fenderstays
BELL
Simple bell
* Pesos basados en cuadros pintados de producción como se muestra en la imagen. Los pesos reales variarán en función del color, tamaño del cuadro y variación de componentes. Las especificaciones están sujetas a cambios sin previo aviso.
S | M | L | XL | |
---|---|---|---|---|
Largo de biela | 170mm | 170mm | 175mm | 175mm |
Ancho de manubrio | 680mm | 680mm | 680mm | 680mm |
Largo de avance | 60mm | 75mm | 75mm | 90mm |
Saddle Width | 155mm | 155mm | 155mm | 155mm |
Largo de poste de asiento | 300mm | 350mm | 400mm | 400mm |
Rake de horquilla | 44mm | 44mm | 44mm | 44mm |
Altura de standover | 762mm | 800mm | 833mm | 875mm |
Stack | 619mm | 619mm | 629mm | 652mm |
Alcance | 396mm | 406mm | 428mm | 441mm |
Largo de tubo de dirección | 135mm | 135mm | 145mm | 170mm |
Ángulo de tubo de dirección | 70° | 70° | 70° | 70° |
BB Drop | -70mm | -70mm | -70mm | -70mm |
Trail | 86mm | 86mm | 86mm | 86mm |
Distancia | 647mm | 657mm | 682mm | 704mm |
Largo de vaina inferior | 478mm | 478mm | 478mm | 478mm |
Distancia entre ejes | 1116mm | 1126mm | 1152mm | 1173mm |
Seat Tube Length, BB Center to Top Vertical | 400mm | 450mm | 500mm | 550mm |
Para las advertencias de seguridad, consulte la documentación en la sección Descargas de Manuales de esta página.
