2006 Fuse IV

Part No.: 9860-1100

0 Reviews

EXPERIENCE � BMX DIRT/STREET/VERT Progression is what keeps you going. It's about…

Colour:

All Colors 2

Size:

One Size

Product Details

EXPERIENCE � BMX DIRT/STREET/VERT Progression is what keeps you going. It's about trying a trick 30 times before you finally pull it, riding the ramps or the street every day, for as long as it takes. It's that feeling inside of determination, mixed with adrenaline, and some fear thrown in for good measure. Sore arms and cut shins are nothing more than battle scars that prove you're trying. This is what BMX is all about: having fun, and becoming a better rider with a bigger bag of tricks. Every Specialized Fuse makes this possible.

Tough, lightweight full Cr-Mo double-butted frame with integrated chain tensioners
Full Cr-Mo threadless fork with CNC, heat treated Cr-Mo steerer with butted 1-1/4" blades
Odyssey 10T CNC'd cog driver with 2x sealed cartridge bearings
Truvativ Luftalarm Team crank with CNC cut 7075 28T chainrings with bolt on grind plate
Specialized Lo-Pro magnesium platform pedals

Technical Specifications

FRAMESET

FRAME

2006 Fuse 4 (20.75""), Full Cr-Mo, double butted/formed 40mm TT/DT, tig welded, internaly relieved head tube w/ stamped badge and weld on rotor plate, threaded Euro BB shell, tube BB yoke, 1pc CS, SS mounted brake bosses, 5mm forged/CNC'd 3D dropouts for 14mm axle w/ integrated chain tensioners

FORK

Full Cr-Mo, 1-1/8"" threadless, Heat treated 1pc CNC Cr-Mo steer w/ internal thread, Butted 1.8-1.2mm Cr-Mo 1-1/4"" blades, 5mm Cr-Mo dropouts for 14mm axle w/ gussets

HEADSET

Tank FS, Nickel plated Cr-Mo cups

SEAT BINDER

forged alloy, single bolt

WHEELS

REAR TIRE

Specialized Compound Pro 20x2.0"", dual compound

RIMS

SUN City Light, 20"", welded, eyelets, Blk front, CP rear

FRONT HUB

Fuse 36h, 14mm hollow axle, sealed cartridge bearing, mid flange

REAR HUB

Fuse 36h Sealed 4x Cartridge Bearing Cassette/Hollow 14mm Axles

SPOKES

2.0mm stainless, Black w/brass nipples

FRONT TIRE

Specialized Rhythm Pro 20x2.1"", wire bead

DRIVETRAIN

FREEWHEEL

10t cog CNC'd driver for cassette hub

CHAIN

KMC 710 KOOL

CRANKSET

Truvativ Luftalarm, forged AL-7050-TV, ISIS, L & R drive compatible, 175mm, self extracting bolts

CHAINRINGS

Truvative CNC cut 7075 28t w/ bolt on grind plate

BOTTOM BRACKET

Truvative Giga Pipe, 4 bearing, alloy cups, ISIS

COCKPIT

STEM

Specialized KO Lite, cold forged alloy, CNC relieved, top-load, 50mm reach with integrated rotor stops

HANDLEBARS

Specialized 100% Cr-Mo 2-piece, 195mm rise x 620mm width, 10 degree backsweep, 5 degree upsweep

GRIPS

Fuse kraton dual file pattern w/ micro flange and CNC'd alloy bar ends

SADDLE

Specialized Fuse SuperLight saddle, aramid sides, SuperLite Foam 9mm hollow Cr-Mo rails with X-Brace, front and rear PU handles

BRAKES

FRONT BRAKE

Tektro single pivot caliper w/soft compound pads

REAR BRAKE

Dia Tech 996 ""Hombre"" w/ ""Fiesta Kit"" and soft compond pads

BRAKE LEVERS

Dia-Compe Tech 77, 2pc hinge clamp w/ forged alloy two finger lever

ACCESSORIES

PEDALS

Specialized Lo-Pro Mag, magnesium platform, 9/16"" oversized heat treated Cr-Mo axle, sealed cartridge bearing, removable allen bolt pins

* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	16	20.5	20.75	21
Rake	38mm	29mm	28mm	38mm
Top Tube Length (Actual)	431.8mm	533.4mm	533.4mm	533.4mm
Seat Tube Length, Center to Top	228.6mm	279.4mm	279.4mm	279.4mm
Bottom Bracket Drop	0mm	0mm	0mm	0mm
Bottom Bracket Height	228.6mm	304.8mm	304.8mm	304.8mm
Standover Height	18mm	23mm	23mm	23mm
Head Tube Length	100mm	100mm	100mm	100mm
Head Tube Angle	73°	74.25°	74.25°	74.25°
Chainstay Length	306mm	362mm	360mm	360mm
Seat Tube Angle	70°	72°	72°	72°
Seatpost Length	0mm	0mm	0mm	0mm
