Turbo Vado 3.0 IGH Step-Through
RAHMEN
E5 Aluminum, bottom bracket motor mount, fully integrated &lockable downtube battery, internal cable routing, lock and front rack mount, sliding dropout
GABEL
SR Suntour MobieA32, 80mm travel, lockout, fender-mounts, integrated light mount
SATTELSTÜTZKLEMME
Alloy, bolt-type, 34.9mm
VORBAU
Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp
LENKER
Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm
LENKERGRIFFE
Specialized Body Geometry Contour, lock-on
SATTEL
Rivo Sport, steel rails, 155mm
SATTELSTÜTZE
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
BREMSE VORNE
Shimano BR-MT200, hydraulic disc, 180mm Centerlock
BREMSE HINTEN
Shimano BR-MT200, hydraulic disc, 180mm 6-bolt
SCHALTHEBEL
enviolo Twist Display Pure
KASSETTE
Gates Carbon Drive CDC 24t sprocket, silver
KETTE
Gates Carbon Drive CDX 122t belt, black
KURBELGARNITUR
Custom alloy forged crankarms
KETTENBLÄTTER
Gates Carbon Drive CDC 50T chainring, black
KETTENKASTEN
custom chaincover
SCHALTWERK
enviolo CVP Multi-Turn
PEDALE
Specialized Commuter w/ grip tape & reflectors
SCHEINWERFER
Lezyne EBIKE MINI STVZO E65, 210 Lumen, 12V
RÜCKLICHT
Spanninga Commuter Glow XE, 12V
STÄNDER
Specialized kickstand, 40mm mount
GEPÄCKTRÄGER
Specialized rack, MIK HD inteface, built-in pannier mounts, 27kg max load
SCHUTZBLECHE
Specialized DRYTECH fenders, 65mm width, aluminum fenderstay
KLINGEL
Simple bell
FELGEN
650b disc, double-wall alloy, pinned, 32h
VORDERRADNABE
Shimano MT400, Centerlock, 15x100mm, 32h
HINTERRADNABE
enviolo CITY, 310% range, 6-bolt, 10x135mm, 32h
SPEICHEN
DT Swiss Industry
VORDERREIFEN
Pathfinder Sport Reflect, 650Bx2.3
HINTERREIFEN
Pathfinder Sport Reflect, 650Bx2.3
SCHLÄUCHE
Schrader, 40mm valve
MOTOR
Specialized 2.0E, 50Nm torque, custom tuned motor, 250W nominal
DISPLAY
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
AKKU
Specialized U2-530, alloy casing, state of charge display, 530Wh
LADEGERÄT
Custom charger, 42V4A w/ Rosenberger plug, 230V
KABELBAUM
Custom wire harness
* Gewichte basieren auf der Produktion lackierter Rahmen, wie abgebildet. Tatsächliche Gewichte variieren je nach Farbgebung, Rahmengröße und Komponentenvariation. Spezifikationen können ohne Vorankündigung geändert werden.
| S | M | L | XL | |
|---|---|---|---|---|
| Kurbellänge | 170mm | 170mm | 170mm | 170mm |
| Lenkerbreite | 680mm | 680mm | 680mm | 680mm |
| Vorbaulänge | 60mm | 60mm | 75mm | 75mm |
| Sattelbreite | 155mm | 155mm | 155mm | 155mm |
| Länge Sattelstütze | 300mm | 400mm | 400mm | 400mm |
| Stack | 625mm | 639mm | 652mm | 676mm |
| Reach | 423mm | 444mm | 464mm | 481mm |
| Steuerrohrlänge | 135mm | 150mm | 165mm | 190mm |
| Steuerrohrwinkel | 68° | 68° | 68° | 68° |
| Tretlagerhöhe | 285mm | 285mm | 285mm | 285mm |
| Tretlagerabsenkung | 70mm | 70mm | 70mm | 70mm |
| Nachlauf | 96mm | 96mm | 96mm | 96mm |
| Gabellänge (komplett) | 480mm | 480mm | 480mm | 480mm |
| Gabelversatz / Offset | 44mm | 44mm | 44mm | 44mm |
| Mitte Tretlager - Mitte V.-Achse | 699mm | 724mm | 750mm | 777mm |
| Kettenstreben-Länge | 470mm | 470mm | 470mm | 470mm |
| Radstand | 1160mm | 1186mm | 1212mm | 1239mm |
| Toptube Length (horizontal) | 585mm | 615mm | 645mm | 675mm |
| Überstandshöhe | 618mm | 617mm | 617mm | 626mm |
| Sitzrohrlänge | 400mm | 450mm | 460mm | 500mm |
| Seat Tube Angle (Virtual) | 75.5° | 75° | 74.5° | 74° |
