Diverge 4 Pro

SRAM Force XPLR

€7,999.00

0 Reviews

Gravel adventure to gravel race—unmatched speed, unrivaled capability, total confidence.

Colour:

Bordeaux Metallic

What's my size?

Imperial

Metric

Enter your height and we'll calculate your size.

Height:

For a more accurate result, include your shin length.

Select a Size

Diverge 4

The Ultimate Getaway Vehicle

Diverge 4

The Ultimate Getaway Vehicle

Race-tuned. Adventure-approved. The Diverge 4 gravel bike is built for full-gas race days and off-grid epics. With Future Shock 3.0, our most responsive frame ever, massive tire clearance, and the biggest internal storage in gravel, the best gravel bike in the world just got better. Chase the horizon—or your rivals—it’s built for both.

At a Glance

Use

Gravel Adventure/Race

Frameset

FACT 9r Carbon

Suspension

Future Shock 3.3

Drivetrain/Wheels

SRAM Force AXS XPLR / Roval Terra CL

Storage

SWAT 4.0

Weight

Diverge Pro: 8.39kg

Diverge 4: The Ulitmate Getaway Vehicle

Technical Specifications

Frameset

Frame

Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout

Suspension

Fork

Future Shock 3.3 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc

Brakes

Front Brake

New SRAM Force E1, hydraulic disc

Rear Brake

New SRAM Force E1, hydraulic disc

Drivetrain

Shift Levers

New SRAM Force AXS E1

Rear Derailleur

New SRAM Force AXS E1 XPLR

Cassette

New SRAM Force E1 XPLR 10-46t, 13sp

Chain

New SRAM Force XPLR, 13sp

Crankset

New SRAM Force E1 XPLR, DUB WIDE, 40t, Quarq Power Meter

Bottom Bracket

SRAM DUB BSA 68 Wide

Wheels & Tires

Front Wheel

Roval Terra CL Rim, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes

Front Tire

Tracer 700x45, Tan Sidewall, Tubeless Ready

Rear Tire

Tracer 700x45, Tan Sidewall, Tubeless Ready

Rear Wheel

Roval Terra CL Rim, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes

Inner Tubes

Presta, 700x32-50mm

Cockpit

Stem

Specialized Pro SL, alloy, 4-bolt

Handlebars

Roval Terra, carbon, 103mm drop x 70mm reach x 12º flare

Tape

Supacaz Super Sticky Kush

Saddle

Power Pro Mirror, Hollow Ti rails

SeatPost

Roval Terra Carbon Seat Post, 20mm Offset

Seat Binder

Specialized Alloy, 30.8mm

Accessories

SWAT

SWAT 4.0 internal downtube storage

Product Details

Product ID

293747

Weight

8.39 kg (18 lb, 7.9 oz)

Weight Size

* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.

Geometry

	49	52	54	56	58	61
Crank Length	165mm	170mm	172.5mm	172.5mm	175mm	175mm
Handlebar Width	380mm	400mm	420mm	420mm	440mm	440mm
Stem Length	60mm	70mm	80mm	90mm	100mm	100mm
Saddle Width	155mm	155mm	143mm	143mm	143mm	143mm
Seatpost Length	330mm	330mm	380mm	380mm	380mm	380mm
Stack	563mm	578mm	592mm	610mm	634mm	659mm
Reach	365mm	374mm	387mm	400mm	412mm	425mm
Head Tube Length	90mm	104mm	116mm	135mm	161mm	187mm
Head Tube Angle	70°	70.5°	71°	71°	71°	71°
BB Drop	85mm	85mm	85mm	85mm	85mm	85mm
Trail	72mm	68mm	65mm	65mm	65mm	65mm
Fork Length, Full	391mm	391mm	391mm	391mm	391mm	391mm
Fork Rake/Offset	55mm	55mm	55mm	55mm	55mm	55mm
Front Center	604mm	613mm	626mm	645mm	665mm	686mm
Chainstay Length	430mm	430mm	430mm	430mm	430mm	430mm
Wheelbase	1019mm	1031mm	1041mm	1060mm	1081mm	1102mm
Top Tube Length, Horizontal	521mm	537mm	556mm	575mm	593mm	613mm
Bike Standover Height	700mm	725mm	754mm	779mm	805mm	832mm
Seat Tube Length	400mm	430mm	470mm	500mm	530mm	560mm
Seat Tube Angle	74.5°	74°	74°	74°	74°	74°
