Technical Specifications
FRAME
Double butted Reynolds 520 Cr-Mo, 21" top tube, externally relieved MID BB shell and integrated head set, hydra-formed chainstays, removable seat-stay mounted U-brake boss, 5mm thick dropouts for 14mm axle
FORK
20" BMX, butted and tapered Cr-Mo blades, 1-1/8" threadless, 1pc CNC Cr-Mo steerer w/ alloy compression bolt, Cr-Mo dropouts for 3/8" axle
HEADSET
Integrated 1-1/8" threadless, Campy-style, full cartridge bearings
STEM
Specialized P.Series BMX, forged alloy, top load, 52mm length, 22.2mm
HANDLEBARS
Specialized P.Series BMX bar, Cr-Mo, 735mm wide, 217mm rise, 11º backsweep, 2º upsweep, 22.2mm
GRIPS
Specialized P.Grip, flanged soft compound, end plugs, 150mm
REAR BRAKE
Wide tire U-brake, die-cast, single bushing, coil spring, 15mm offset arms, w/ 1pc. black pads
BRAKE LEVERS
Lever "U" brake, 15mm cable pull
FREEWHEEL
1 pc. CNC 1/2" x 1/8" x 9t driver
CHAIN
KMC Z-510H, 1/2" x 1/8", anti-drop inner links
CRANKSET
3pc. tubular heat treated Cr-Mo, 48-spline, 175mm
CHAINRINGS
25t, Cr-Mo, for 48-spline
BOTTOM BRACKET
MID BB, 2x sealed cartridge bearing w/ 19mm, 48-spline Cr-Mo spindle, alloy tube and cone spacers
PEDALS
Specialized P.Series NYLON platform w/ molded pins, loose ball, 9/16"
RIMS
Specialized P.Series, 20", alloy double-wall, triple void, 35mm, pin joint, 36h
FRONT HUB
Specialized P.Series BMX, female bolt-in, sealed cartridge bearings, alloy axle, 36h
REAR HUB
Specialized P.Series BMX, sealed cartridge bearings, hollow axle, 36h
SPOKES
Stainless, 2.0mm (14g)
FRONT TIRE
Specialized Compound Street, 20x2.3", wire bead, 30TPI
REAR TIRE
Specialized Compound Street, 20x2.3", wire bead, 30TPI
INNER TUBES
Schraeder valve
SADDLE
Specialized P.Series 1pc co-molded composite saddle & alloy 25.4mm seat post combination w/ debossed "P. Series" logo padded cover
SEATPOST
Alloy, no offset, 25.4mm, integrated w/ saddle
SEAT BINDER
Integrated Cr-Mo bolt and nylock nut
NOTES
Owner's manual, chainguard, reflectors
