Technical Specifications
FRAME
Specialized A1 Premium Aluminum 20" frame, front suspension geo, formed toptube/downtube, forged dropouts, alloy replaceable der. hanger
FORK
SR Suntour SF9-XCT-JR-20, 1pc alloy lower, coil/MCU spring, 1-1/8" Hi-Ten steerer, direct press type dust seal, for both V+Disc brake mount, preload adjust, 40mm travel
HEADSET
1-1/8" threadless, cartridge w/ seals
STEM
Alloy Ahead, 4 bolt, 20º rise, 25.4mm clamp
HANDLEBARS
Alloy riser bar, 25mm rise, 10º backsweep, 4º upsweep, 25.4mm
GRIPS
Specialized Kraton, Revo type
FRONT BRAKE
"V" brake, alloy linear pull, 1pc. pad
REAR BRAKE
"V" brake, alloy linear pull, 1pc. pad
BRAKE LEVERS
Alloy, linear pull compatible
REAR DERAILLEUR
Shimano FT30, 7-speed, short cage
SHIFT LEVERS
Shimano RS-35, 6-speed, Revo Twist
CASSETTE
Shimano, 6-speed freewheel, 14-28
CHAIN
KMC HV500, 1/2" x 3/32"
CRANKSET
Forged alloy arms w/ single outer chainguard
CHAINRINGS
36T, steel w/ chainguard
BOTTOM BRACKET
Water sealed, loose ball, 68mm x 128mm
PEDALS
Composite platform, w/ reflectors, 9/16"
RIMS
20", alloy, single-wall, pin joint, 32h
FRONT HUB
Alloy, nutted axle, 32h
REAR HUB
Alloy, freewheel type, nutted axle, 32h
SPOKES
Stainless, 2.0mm (14g)
FRONT TIRE
Specialized Roller, 20x2.125", wire bead, 30TPI
REAR TIRE
Specialized Roller, 20x2.125", wire bead, 30TPI
INNER TUBES
Schrader valve
SADDLE
Specialized Kids, 7mm rail w/ clamp
SEATPOST
Alloy, 27.2mm, single bolt
SEAT BINDER
34.9mm, alloy, nylon washer
NOTES
chainstay protector, reflectors, clear coat, owners manual
