Technische Spezifikationen
RAHMEN
Double butted Reynolds 520 Cr-Mo, singlespeed specific, integrated head set, MID BB shell, hydra-formed chainstays, 3D forged horizontal drop outs w/ intl std disc mount
GABEL
Manitou Circus Comp, coil spring, 1-1/8" steel steerer, Hyd. Damping and preload adj., open 9mm axle drop outs, mag post mount lower, 32mm steel stanchions, 80mm
STEUERSATZ
Integrated 1-1/8" threadless, Campy-style, full cartridge bearings
VORBAU
Specialized P.Series BMX, forged alloy, top load, 52mm length, 22.2mm
LENKER
Specialized P.Series MTB Street, heat-treated butted Cr-Mo, 720mm wide, 11º backsweep, 2º upsweep, 75mm rise
LENKERGRIFFE
Specialized P.Grip, flanged soft compound, end plugs, 150mm
VORDERRADBREMSE
Tektro NOVELA, mechanical disc, dual pad angle adjustment, 160mm rotor
HINTERRADBREMSE
Tektro NOVELA, mechanical disc, dual pad angle adjustment, 140mm rotor
KASSETTE
Singlespeed, Cr-Mo, 12t
KETTE
KMC Z-510H, 1/2" x 1/8", anti-drop inner links
KURBELGARNITUR
3pc. tubular heat treated Cr-Mo 8-spline, 175mm
KETTENBLÄTTER
25t, 2.5mm thick steel
INNENLAGER
MID BB, 2x sealed cartridge bearing w/ 19mm, 8-spline Cr-Mo spindle, alloy tube and cone spacers
PEDALE
Specialized P.Series NYLON platform w/ molded pins, loose ball, 9/16"
FELGEN
Specialized P.Series, 26", alloy double-wall, triple void, 32mm, pin joint, 36h
VORDERRADNABE
Specialized P.Series MTB, alloy, sealed cartridge bearings, Cr-Mo axle, 36h
HINTERRADNABE
Specialized P.Series Dirt, alloy, cartridge bearings, 36h
SPEICHEN
Stainless, 2.0mm (14g)
VORDERREIFEN
Specialized Rhythm Lite Sport, 26x2.3", wire bead, 60TPI
HINTERREIFEN
Specialized Compound Control, 26x2.2", wire bead, 60TPI
SCHLÄUCHE
Schraeder valve
SATTEL
Specialized P.Series 1pc co-molded composite saddle & alloy 25.4mm seat post combination w/ debossed "P. Series" logo padded cover
SATTELSTÜTZE
Alloy, no offset, 25.4mm, integrated w/ saddle
SATTELSTÜTZKLEMME
Integrated Cr-Mo bolt and nylock nut
ANMERKUNGEN
Reflectors, owners manual
