Spécifications techniques
CADRE
Specialized Jett M4 Aluminum 29" frame, Women's XC 29" Performance geometry and tubesets, fully butted w/ smooth welding, integrated headset, forged post-mount 160mm dropouts w/ replaceable der. hanger, disc only
FOURCHE
RockShox XC28 29", TurnKey hydraulic damping w/ lock out, coil spring w/ custom women's spring weights, 1-1/8" alloy steerer, mag disc only post mount lower, 28mm steel stanchion, preload and rebound adj., 80mm travel, 51mm offset on size 15/SM, 46mm offset on sizes 17/MD and 19/LG
JEU DE DIRECTION
Integrated 1-1/8" threadless, Campy-style, full cartridge bearings
POTENCE
Specialized 3D forged alloy, 4 bolt clamp, 6º rise, 31.8mm
GUIDON
Flat bar, 6061 double butted alloy, 660mm wide, 10º backsweep, 4º upsweep, 31.8mm
POIGNÉES
Specialized Women's Body Geometry XCT, Kraton rubber w/ gel, closed end, 120mm, lock-on
FREIN AVANT
Tektro Draco 2, hydraulic disc, dual piston, Lightwave style rotor, 160mm
FREIN ARRIÈRE
Tektro Draco 2, hydraulic disc, dual piston, Lightwave style rotor, 160mm
LEVIERS DE FREINS
Tektro Draco 2, hydraulic w/ women's shorter reach lever
DÉRAILLEUR AVANT
Shimano Acera, 9-speed, 34.9 clamp, high-mount, bottom swing
DÉRAILLEUR ARRIÈRE
Shimano Deore Shadow, 9-speed, SGS cage
MANETTES DE DÉRAILLEURS
Shimano Alivio, 9-speed Rapidfire plus, SL type w/ optical display
CASSETTE
Shimano HG20-9, 9-speed cassette, 11-34
CHAÎNE
KMC X-9, 9-speed w/ reusable Missing Link
PÉDALIER
SR Suntour XCR, 9-speed, Octalink
JEU DE PÉDALIER
Shimano, Octalink spline, cartridge bearing, 73mm
PÉDALES
Composite platform, w/ reflectors, 9/16"
JANTES
Disc, 29", alloy double-wall, 26mm, pin joint, 36h
MOYEU AVANT
Specialized MTB disc hub, alloy, Hi Lo flange, RCC ball bearing system, steel axle, QR, 32h
MOYEU ARRIÈRE
Specialized MTB disc hub, alloy, Hi Lo flange, RCC ball bearing system, steel axle, steel cassette body, QR, 32h
RAYONS
Stainless, 2.0mm (14g)
PNEU AVANT
Specialized Ground Control Sport, 29x2.1", wire bead, 60TPI
PNEU ARRIÈRE
Specialized Ground Control Sport, 29x2.1", wire bead, 60TPI
CHAMBRES À AIR
Presta valve
SELLE
Specialized Women's Body Geometry Riva WMN Comp, steel rails, 155mm width
TIGE DE SELLE
Specialized 2 bolt head, forged alloy, 12.5mm offset, micro adjust, 27.2mm, 350mm or 400mm
COLLIER DE TIGE DE SELLE
31.8mm, forged alloy QR, brass washer
NOTES
chainstay protector, reflectors, clear coat, owners manual
