Specialized Bicycle Components

Crossroads
Sport

WHERE TO BUY ›

Size	SM	MD	LG	XL	XXL
Seat-Tube Length, B-B Center to Top	425mm	485mm	535mm	584mm	634mm
Top-Tube Length, Horizontal	600mm	615mm	630mm	645mm	660mm
B-B Drop	65mm	65mm	65mm	65mm	65mm
Chain-Stay Length	465mm	465mm	465mm	465mm	465mm
Seat-Tube Angle	71°	71°	71°	71°	71°
Head-Tube Angle	69.5°	70.5°	70.5°	70.5°	70.5°
Fork Rake	55mm	51mm	51mm	51mm	51mm
Trail	74mm	72mm	72mm	72mm	72mm
Front-Center	654mm	655mm	670mm	685mm	701mm
Wheelbase	1111mm	1112mm	1128mm	1143mm	1158mm
Stand-Over Height	757mm	799mm	828mm	860mm	895mm
Head-Tube Length	145mm	175mm	190mm	205mm	225mm
Handle-Bar Width	660mm	660mm	660mm	660mm	660mm
Stem Length	50mm	50mm	50mm	50mm	50mm
Crank Length	170mm	175mm	175mm	175mm	175mm
Seat-Post Length	350mm	350mm	350mm	350mm	350mm
