Specialized Bicycle Components

Camber Comp
Carbon

WHERE TO BUY ›

Size	S	M	L	XL	XXL
Seat Tube Length - Center to Top	394mm	445mm	483mm	533mm	584mm
Top Tube Length (Horizontal)	560mm	590mm	617mm	645mm	665mm
Top Tube Length (Actual)	532mm	561mm	587mm	611mm	631mm
Chainstay Length	447mm	447mm	447mm	447mm	447mm
Bottom Bracket Height - Low Setting	336mm	336mm	336mm	336mm	336mm
Seat Tube Angle (Actual) - Low Setting	71°	71°	71°	71°	71°
Seat Tube Angle (Effective) - Low Setting	74°	74°	74°	74°	74°
Head Tube Angle - Low Setting	70°	70°	70°	70°	70°
Wheel Base	1087mm	1118mm	1147mm	1176mm	1198mm
Standover Height	768mm	772mm	784mm	801mm	805mm
Head Tube Height	90mm	110mm	130mm	150mm	170mm
Handlebar Width	720mm	720mm	720mm	720mm	720mm
Stem Length	90mm	90mm	100mm	100mm	100mm
Crank Length	170mm	175mm	175mm	175mm	175mm
Seatpost Length	380mm	380mm	380mm	380mm	380mm
Stack	582mm	601mm	620mm	639mm	658mm
Reach	393mm	418mm	439mm	462mm	476mm
Ground-Top	912mm	931mm	950mm	969mm	988mm
