Technical Specifications
FRAME
M5 hydroformed tubing, 29" geometry, tapered HT, PF30 BB, Command Post routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, bolt-on cable guides, 110mm travel
REAR SHOCK
Custom Monarch RL with AUTOSAG, air spring, LO and rebound adj., 197x48mm
FORK
RockShox Reba RL 29, Solo air spring, tapered alloy steerer, rebound adj., standard QR dropouts, 110mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Campy style upper with 1-1/2" lower, cartridge bearings
STEM
Specialized XC Trail, 6061 alloy, 4-bolt, 8-degree rise, 31.8mm clamp, 6-degree rise, S: 70mm, M: 90, L:100, XL:110mm
HANDLEBARS
Specialized XC Mini-Riser, 7050 butted alloy, 720mm wide, 10mm rise, 10-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, half-waffle aramid-infused, S/M: Regular, Others: XL thickness
FRONT BRAKE
Custom Avid Elixir 3R, hydraulic disc, semi-metallic pad, HS-1 rotor S/M:180mm, Others: 200mm
REAR BRAKE
Custom Avid Elixir 3R, hydraulic disc, semi-metallic pad, HS-1 rotor S/M:160mm, Others: 180mm
BRAKE LEVERS
Custom Avid Elixir 3R, tool-less reach adj.
FRONT DERAILLEUR
SRAM X7, 10-speed, S3 direct mount for DMD, bottom pull
REAR DERAILLEUR
SRAM X9, 10-speed, mid cage, Type 2
SHIFT LEVERS
SRAM X7, 10-speed, aluminum trigger, w/MatchMaker clamp
CASSETTE
SRAM PG-1030, 10-speed, 11-36
CHAIN
KMC X10, nickel plate, reusable Missing Link
CRANKSET
Custom SRAM S-1250, 10-speed XC Trail double w/ alloy guard, PF30 spindle, S: 170mm, Others: 175mm
CHAINRINGS
36/22, w/ alloy guard
BOTTOM BRACKET
SRAM PF30, OS press-in bearing, sealed cartridge
PEDALS
Resin Test Ride Pedals with toe clips, CEN std.
RIMS
Roval 29, alloy disc, 26mm wide, 32h
FRONT HUB
Specialized Hi Lo disc, OS28 end caps, sealed cartridge bearing, QR, 32h
REAR HUB
New Specialized Hi Lo disc, 4x-sealed cartridge bearing, 12mm thru-axle, 32h
FRONT TYRE
Specialized Ground Control, 2Bliss Ready, 60TPI, aramid bead, 29x2.3"
REAR TYRE
Specialized Ground Control, 2Bliss Ready, 60TPI, aramid bead, 29x2.1"
INNER TUBES
Ultralight presta
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Specialized 2014 butted alloy, single bolt setback, 30.9mm, S/M: 350mm, Others: 400mm
SEAT BINDER
Specialized 7050 hard anodized alloy collar w/ QR, 34.9mm, black
NOTES
Protective clear coat, derailleur hanger, reflectors, owners manual
